Operating System Page 3-15

DAT

<

Correctly formatted data fields separated by either column

leaders or commas; null fields acceptable.

PGM

<

Line number followed by a period, opcode, mnemonic,

parameter (if required), semi-colon, and comments, where

opcode, semi-colon, and comments are optional. String

constants in the parameter field may be enclosed in quotes.

Control characters in the parameter field are expressed as

^x where ^ is the control and x represents the alphanumeric

portion of the control character. Example: carriage return,

line feed is represented in control characters as ^M ^J.

Mode 3-3 Load Serial Memory
The Load Serial Memory submode is used to load a FieldBook memory image into the
FieldBook from another FieldBook or computer through the RS-232C port. Instructions for
using Mode 3-3 follow.

❖ Caution: The entire contents of the FieldBook's memory is lost when a new memory image is
loaded. Before you load a new memory image, make sure you save copies of data and programs you
want to keep on another FieldBook or computer to be reloaded as needed.

Keyboard Entry

Next Message Shown

Action

MODE?

Enter a 3 for LOAD SER Mode.

LOAD SER 1,2,3

Enter a 3 for submode MEM.

DAT, FILE, MEM

LOAD SER MEM

The mating call is sent and the memory image
is loaded into the FieldBook.

Guide to Loading Serial Memory
❏ We recommend that you reset the FieldBook using the @@SYS/RESET connector before

loading a memory image. Refer to Section 6, System Resest and @@SYS Inhibit Connector,
for details. Remember that the RESET connector erases everything stored in memory.

❏ Before you load a a memory image into the FieldBook, you must set the FieldBook up to

receive information. Refer to Section 5, Communications, for details.

❏ The input file (memory image) must have been generated by a FieldBook in Mode 2-3.
