Juniper Systems JS600 User Manual
Page 42
Page 3-26 Operating System
Mode 7-2 Misc Batteries
The Misc Batteries submode is not applicable to this version of the FieldBook.
Mode 7-3 Misc Terminal
In the Misc Terminal submode, the FieldBook functions as a terminal to another RS-232C
device, such as a printer, computer, or another FieldBook. Instructions for using Mode 7-3
follow.
Keyboard Entry
Next Message Shown
Action
MODE?
Enter a 7 for MISC Mode.
7
MISC 1,2,3
Enter a 3 for submode TERM.
CLK, BAT, TERM
3
_
A blank screen is initially displayed. As
information is received from the connected
device, it is displayed on the FieldBook.
Information keyed in on the FieldBook
keyboard is sent to the connected device.
Guide to Using the FieldBook as a Terminal
❏ Before you can use the FieldBook as a terminal, you must set the FieldBook up to receive
and send information. Refer to Section 5, Sending and Receiving Information, for details.
❏ This mode can be used to test the communication link between the FieldBook and another
RS-232C device.
