Page 3-12 Operating System
Guide to Transmitting Serial Files
❏ To initiate transmission, send a request character from the connected device or key it in
on the FieldBook's keyboard.
❏ Checksums, if enabled, follow each line in the body of a data file.
❏ An end-of-line sequence follows every output line. This is typically a carriage return
followed by a line feed.
❏ One blank is output between the data and the checksum, but it is not counted when
calculating the checksum
❏ An & is sent at the end of each file.
Mode 2-3 Transmit Serial Memory
The Transmit Serial Memory submode is used to transmit an image of the entire FieldBook
memory in hexadecimal form through the RS-232C port to a computer or another FieldBook
for reloading at a later time. Instructions for using Mode 2-3 follow.
Keyboard Entry Next Message Shown Action
MODE? Enter a 2 for TRANSMIT Mode.
2 XMIT SER 1,2,3 Enter a 3 for submode MEM.
DAT, FILE, MEM
3 XMIT SER MEM No action.
CP=D The bottom line shows the current settings of
L=A R=B C=C S=D the line request, repeat request, continuous
request, and stop request characters. In the
upper right corner is the current parameter
or the request character currently in force.
Guide to Transmitting Serial Memory
❏ To initiate transmission, send a request character from the connected device or key it in
on the FieldBook's keyboard.
❏ The first line of the output file contains the total number of bytes being saved, expressed
as a four-digit hexadecimal number.
❏ The final line is a four-digit hexadecimal checksum.
❏ The body of the memory image transmitted between the two checksums should be a block
of 64 character lines of hexadecimal numbers. If the lines are longer or shorter than 64
characters, the memory image has not transmitted correctly to the connected device.
