Operating System Page 3-19
❏ The autolog start time is based on the internal 24-hour system clock. For example, if your
logging units are minutes and your start time is 45, the FieldBook will execute the autolog
program the next time the minute field of the system clock reads 45.
Mode 5-2 Set Communication Protocol
The Communication Protocol submode is used to set up the following communication
parameters:
- Baud rate - Data bits
- Parity - Stop bits
- Duplex - Transmit prompts
- Line request character - Repeat request character
- Continuous request character - Stop request character
- Input line terminator - Input maximum length
- Transmit delay - Checksum
- End of line sequence - End of page sequence
- End of file sequence - Mating call
Characteristics of the FieldBook's internal beeper are also set up in this mode.
Use the left Í and right Î arrow keys to view each of the parameters. Instructions for using
Mode 5-2 follow.
Keyboard Entry Next Message Shown Action
MODE? Enter a 5 for SET Mode.
5 SET 1,2 Enter a 2 for submode PROTOCOL.
2 BAUD Enter the desired baud rate (bits transmitted
L 1!_9600 or received per second). Valid entries are: 300,
600, 1200, 2400, 4800, 9600 (default), and
19200.
Baud Rate DATA BITS 7/8 Enter the number of data bits desired per
or L 1!8 word. Valid entries are 7 and 8 (default).
just to
accept default
Data Bits PARITY E/O/N Enter the parity settings for transmitted data.
or L 1!N The FieldBook does not check parity when
just to receiving data. Valid entries are:
accept default E = Eighth parity bit set for even parity
O = Eighth parity bit set for odd parity
N = No parity (default)
