Juniper Systems Allegro MX Quick Start User Manual
Quick start guide, Field pc
Quick Start Guide
Get your Field PC up and running!
On both sides, slide latches up to
open battery compartment door.
1
Place battery pack in the
compartment and slide right.
2
Close battery compartment with
one hand while sliding both latches
down firmly with the other hand.
3
Plug battery charger into wall
outlet, then into the Field PC.
Follow on-screen instructions.
4
Select (Enter percentage
and capacity) and set charge
percentage to 10.
5
Charge for 6 hours.
6
1
Stylus
2
USB Client
3
USB Host
4
9-pin serial port
5
12V DC jack
6
Top lanyard cleats
The anatomy of your Field PC
7
Touchscreen/Display
8
Power button
9
Expansion card door
10
Battery door
11
Battery door latches
12
Bottom lanyard cleats
6
7
11
8
9
10
5
4
2
1
3
12
part# 20028_01
• English
• 简体中文
• 繁體中文
• Français
• Deutsch
• Polski
• Español
• Svenska
Documentation CD
6 hours
ULTRA-RUGGED
FIELD PC
