TOSHIBA
TMP87CM24A/P24A
Table 2-1. Time Base Timer Interrupt Frequency
TBTCK
NORMAL1/2, DLE1/2mode
SLOW, SLEEP mode
Interrupt Frequency
DV7CK = 0 DV7CK= 1 Atfc = 8MHz At fs = 32.768 kHz
000 fc/223 fs/2^5 fs / 2
0.95 Hz 1 Hz
001 fc/2^''
fs/2^3 fs/2^3
3.81 4
010 fc/2^^ fs/2S - 122.07 128
oil fc/2'^ fs/2^ - 488.28 512
100
fc/2^3
fs/25 - 976.56 1024
101 fc/2^2 fs/2^ - 1953.12 2048
110 fc/2" fs/23 - 3906.25 4096
111 fc/29 fs/2 - 15625 16384
2.4 Divider Output (DVO)
A 50% duty pulse can be output using the divider output circuit, which is useful for piezo-electric buzzer
drive. Divider output is from pin P13 (DVO). The P13 output latch should be set to "1" and then the P13
should be configured as an output mode.
Divider output circuit is controlled by the control register (TBTCR) shown in Figure 2-12.
TBTCR
(0036 h )
7 6 5 4 3 2 1 0
DVOEN DVpCK (DV7CK) (TBTEN) ,(TBTCK), (Initial value : 0**0 0***)
DVOEN Divider output enable/disable
0
1
Disable
Enable
00 : fc/2^3 or fs/2^[Hz]
R/W
D\/nrK
Divider output (DVO) 01 : fc/2^2 or fs/2'^
frequency selection 10 : fc/2" or fs/2^
11 : fc/2^° or fs/22
Note: fc: High-frequency clock [Hz], fs: Low-frequency clock [Hz], *: Don't care
Figure 2-12. Divider Output Control Register
Example : 1 kHz pulse output (at fc = 8 MHz)
SET (P1).3 ; PI 3 output latch <-1
LD (PI CR), 00001OOOB ; Configures PI 3 as an output mode
LD (TBTCR), 10000000B ; DVOEN<-1, DVOCK<-00
Table 2-2. Frequency of Divider Output
DVOCK
Frequency of
Divider Output
At fc = 4.194304 MHz Atfc = 8MHz At fs = 32.768 kHz
00 fc/2’^
or
fs/2= 0.512 [kHz] 0.976 [kHz] 1.024 [kHz]
01 fc/2’2 fs/2^ 1.024 1.953 2.048
10 fc/2" fs/2^ 2.048 3.906 4.096
11 fc/2’° fs/2^ 4.096 7.812 8.192
