TMP87PP24A
Recomended Oscillating Condition ( I ) (Vss = o v, VDD = 4.5to5.5 v, Topr= - ioto70°C)
Parameter Osillator Frequency
Recommender
Oscillator
Recommended
Condition
Cl C 2
KYOCERA KBR8.0M 30pF 30pF
Standard/Lead Type CSA8.00MTZ built-in built-in
(MURATA) CST8.00MTW 30pF 30pF
Ceramic Resonator 8MHz
Standard/SMP Type
(MURATA)
CSAC8.00MT
30pF 30pF
High-
frequency
Standard/Small ChipType CSTC8.00MT
(MURATA)
built-in
30pF
built-in
30pF
4MHz KYOCERA KBR4.0MS 30pF 30pF
8MHz TOYOCOM 21 OB 8.0000
Crystal Oscillator
4MHz TOYOCOM 204B 4.0000
20pF 20pF
Low-frequency Crystal Oscillator 32.768 kHz NDK MX-38T 15pF 15pF
Recomended Oscillating Condition (II) (Vss = ov, VDD = 2.2to5.5v, Topr= - ioto70°C)
Parameter Osillator Frequency
Recommender
Oscillator
Recommended
Condition
Cl C 2
Standard/Lead Type CSA4.00MG 30pF 30pF
(MURATA) CST4.00MGW
built-in
30pF
built-in
30pF
High-
frequency
Ceramic Resonator 4MHz
Standard/SMD Type
(MURATA)
CSA4.00MGC
CSAC4.00MGCM
30pF 30pF
CSTC4.00MG built-in built-in
30pF 30pF
Standard/Small ChipType CSTCS4.00MG
built-in
lOpF
built-in
lOpF
XIN XOUT
□ □
C 2
/77 /77
(1) High-frequency
□ □
^D^■
C 2
/77 /77
(2) Low-frequency
Notel: When used in high electric field such as a picture tube, the package is recommended to be
electrically shielded to maintain a regular operation.
Note2: The product numbers and specifications of the resonators by Murata Manufacturing Co., Ltd.
are subject to change. For up-to-date information, please refer to the following URL;
http ://www.murata.co.jp/search/index.html
