TMP87CM24A/P24A
Other specification for phenomena (2)
Please refer the Figure 2-57)
Topr= -10 to 70 °C
Symbol
Item
Condition
Min
Typ.
Max
Unit
e)
T start of oscillator
fc = 8MHz
MURATA CSACS8.00MT
-
100
-
Vdd = 5V± 10%
KYOCERA KBR8.0M
-
100
-
Cin/out= 10 to 30 pF
TOYOKOM 2108 8.0000
-
1.5
-
ms
Ta = 25°C
(X' tal)
fc = 4MHz
MURATACSAC4.00MGC
-
60
-
Vdd = 5V± 10%
Cin/out= 10 to 30 pF
CSA4.00MG
-
60
-
CST4.00MGW
-
60
-
Ta = 25°C
KYOCERA KBR4.0MS
-
60
-
TOYOKOM 204B 4.0000
-
3.0
-
ms
(X' tal)
fc = 4MHz
MURATACSAC4.00MGC
-
200
-
Vdd = 3V± 10%
Cin/out= 10 to 30 pF
CSA4.00MG
-
200
-
CST4.00MGW
-
200
-
Ta = 25°C
KYOCERA KBR4.0MS
-
200
-
TOYOKOM 204B 4.0000
-
10
-
ms
(X' tal)
f)
Low pulse period of
after power on
e) x5
RESET
+
-
-
s
12/fc
Note: Typical values show those at Торг = 25°C
