TMP87CM24A/P24A
Table 1-4. Watchdog Timer Detection Time
Operating mode Detection time
NORMAL1 NORMAL2 SLOW Atfc = 8 MHz At fs = 32.768 kHz
2 ^Vfc [s] 2 ^Vfc, 2’7fs rVh 4.194 s 4s
2 ^Vfc 2 ^Vfc, 2 ’Vfs 2 ’Vfs 1.048 ms 1 s
2 'Vfc 2 ^Vfc, 2 ’Vfs — 262.1 ms 250 ms
2’7fc 2’7fc, 2 "/fs — 65.5 ms 62.5 ms
(2) Watchdog Timer Enable
The watchdog timer is enabled by setting WDTEN (bit 3 in WDTCR1) to " 1 W D T E N is initialized to
" 1 " during reset, so the watchdog timer operates immediately after reset is released.
Example: Enables watchdog timer
LD (WDTCR1), 00001OOOB ; WDTEN<-1
(3) Watchdog Timer Disable
The watchdog timer is disabled by writing the disable code (B1 h ) to WDTCR2 after clearing WDTEN
(bit 3 in WDTCR1) to "0". The watchdog timer is not disabled if this procedure is reversed and the
disable code is written to WDTCR2 before WDTEN is cleared to "0".
During disabling the watchdog timer, the binary counters are cleared to "0".
Example: Disables watchdog timer
LDW (WDTCR1), 0B101H ; WDTEN<-0,WDTCR1<-disable code
1.10.3 Watchdog Timer Interrupt (INTWDT)
This is a pseudo non-maskable interrupt which can be accepted regardless of the contents of the EIR. If a
watchdog timer interrupt or a software interrupt is already accepted, however, the new watchdog timer
interrupt waits until the previous interrupt processing is completed (the end of the [RETN] instruction
execution).
The stack pointer (SP) should be initialized before using the watchdog timer output as an interrupt
source with WDTOUT.
Example : Watchdog timer interrupt setting up.
LD SP, 083FH ;
LD (WDTCR1), 00001 OOOB ;
Sets the stack poi nter
WDTOUT<-0
