2.7.3 Usage Graphs
There are four built­in usage graphs that will display usage levels during the specified time period.
Click the Date Range drop­down to change the time period reported.
Each bar in the graph will represent the next smaller unit of time. There will be two bars per unit
of time: one for sent faxes, the other for received.
● Fax Traffic: Graphs number of faxes sent and received.
● Fax Page Traffic: Graphs number of pages sent and received.
● Fax Connection Time: Graphs call duration for sent and received calls.
● Port Utilization: Graphs maximum port usage during each time period. This is useful for
capacity planning. If the server ever uses all available ports, it is possible for inbound
callers to get busy signals.
