FaxBack NET SatisFAXtion 9.0 - Fax Server Manual - Manual (Page 181)

rings_before_answer [dword 0–255]: Number of rings before modem accepts call. Default:
1.
ser_device_name [string]: Win32 name for the serial port in the format of COMXXX where
XXX can be 001–999. This does not need to be specified if the tapi_modem_name is specified.
Format: Up to 6 characters. init_string [string]: This is the basic modem initialization string. It
should reset the modem and init the required flow control. Format: Up to 80 characters.
Default: &F&C1&D2V1E0S0=0S7=90^^.
All modem commands start with AT, so this string does not need AT. The symbols
in the string mean the following:
^ 2­second pause
\ Carriage return. There is a wait of init_string_timeout_msecs after carriage return to wait an
OK to be returned.
\\ Specifies a single \
^^\ This is interpreted as \^^
init_string_timeout_msecs [dword 0–65535]: How long to wait for response after CR in
the init_string if there are no 2­second pauses before or after the CR . Default: 5000 .
io_buffer_size [dword 0–65535]: This is the size of the image buffer. The necessary buffer
size depends on host CPU speed and load as well as connect speed. This buffer directly adds
to driver page locked memory use so should be as small as possible. However, too small a
buffer will cause faxes to fail. Default: 20480 .
show_console_scroll_back_buffer_size [dword 0–4294967295]: When the debug output
is CONSOLE , this is how big of a buffer to be used for scrollback. Default: 282144 .
show_ring0_buffer_size [dword 0–4294967295 ]: How big of buffer for the page locked
debug buffer that ring0 code writes to and ring3 code extracts from (on a thread) to the
debugging output. This should be larger for when using serial capture mode since so much
more data is written for debug. It should probably be only about 1K for when using T.30
debug since the frequency and amount of T.30 debug is small enough that the ring3 code
can easily keep up writing to the show output. Default: 65536 .
debug_show_file_path [string(256)]: Partial path or complete path and file name of where
to create debug file. If the debug_show_output is set for CONSOLE and the
debug_show_file_path is specified in the registry, then you can get both CONSOLE and FILE
debug output simultaneously. This is a device specific setting, but you can set the default
for all devices by specifying this under the global icanfax section.
csid [string(20)]: The CSI for receive and the TSI for send.
allowed_receive_image_types [string]: These settings control the image types that the
device can send and receive via the T.30 protocol over the telephone network. To receive or
send some image types, the corresponding allowed_receive / send_transfer_type setting must
include ECM. Format: Comma separated list of the following. Default: 1D,2D,T6,JBIG .
1D
Proprietary FaxBack, Inc. 2014 181
