Carrier 48/50PD05 - Manual (Page 98)

98
Table 58 — Fan Performance - 50PD05 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 422 0.11 548 0.19 652 0.26 745 0.35 831 0.44
1300 439 0.13 561 0.21 662 0.29 752 0.38 835 0.47
1400 457 0.16 577 0.24 674 0.33 761 0.42 842 0.51
1500 477 0.19 593 0.27 688 0.37 773 0.46 851 0.56
1600 498 0.22 611 0.31 704 0.41 786 0.51 862 0.61
1700 521 0.25 630 0.35 720 0.46 801 0.56 875 0.67
1800 545 0.29 650 0.40 738 0.51 817 0.62 889 0.73
1900 569 0.34 672 0.45 757 0.57 834 0.68 904 0.80
2000 595 0.39 694 0.51 777 0.63 852 0.75 921 0.87
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 911 0.53 986 0.63 1056 0.74 1123 0.85 1187 0.96
1300 913 0.57 986 0.68 1056 0.78 1122 0.90 1185 1.01
1400 918 0.62 989 0.72 1058 0.84 1123 0.95 1185 1.07
1500 925 0.67 995 0.78 1061 0.89 1125 1.01 1186 1.14
1600 934 0.72 1002 0.84 1067 0.95 1129 1.08 1189 1.21
1700 944 0.78 1010 0.90 1074 1.02 1135 1.15 1194 1.28
1800 956 0.85 1021 0.97 1083 1.09 1143 1.23 1200 1.36
1900 970 0.92 1033 1.04 1094 1.17 1152 1.31 1208 1.45
2000 985 1.00 1047 1.13 1106 1.26 1162 1.40 1217 1.54
LEGEND
Bhp -- Brake Horsepower
__
High Range Motor/Drive Required
NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
Table 59 — Fan Performance -- 50PD06 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 491 0.19 604 0.28 697 0.37 781 0.47 859 0.57
1600 513 0.23 623 0.32 714 0.42 795 0.52 871 0.62
1700 537 0.27 643 0.37 731 0.47 810 0.57 884 0.68
1800 561 0.31 664 0.42 750 0.52 827 0.63 899 0.75
1900 586 0.36 686 0.47 770 0.58 845 0.70 915 0.82
2000 613 0.41 709 0.53 790 0.65 864 0.77 932 0.89
2100 640 0.47 732 0.60 812 0.72 884 0.85 950 0.97
2200 667 0.54 757 0.67 834 0.80 904 0.93 969 1.06
2300 695 0.61 782 0.75 857 0.89 926 1.02 989 1.16
2400 724 0.69 807 0.84 881 0.98 948 1.12 1010 1.26
2500 753 0.78 833 0.93 905 1.08 971 1.23 1032 1.38
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 932 0.68 1002 0.79 1068 0.91 1132 1.03 1192 1.15
1600 942 0.73 1009 0.85 1074 0.97 1136 1.09 1196 1.22
1700 953 0.80 1019 0.91 1082 1.04 1143 1.17 1201 1.30
1800 966 0.86 1030 0.99 1092 1.11 1151 1.24 1208 1.38
1900 980 0.94 1043 1.06 1103 1.19 1161 1.33 1217 1.47
2000 996 1.02 1057 1.15 1115 1.28 1172 1.42 1227 1.56
2100 1012 1.11 1072 1.24 1129 1.38 1184 1.52 1238 1.67
2200 1030 1.20 1088 1.34 1144 1.48 1198 1.63 1251 1.78
2300 1049 1.30 1106 1.44 1160 1.59 1213 1.74 1265 1.89
2400 1068 1.41 1124 1.56 1178 1.71 1229 1.86 1279 2.02
2500 1089 1.53 1143 1.68 1196 1.84 1246 1.99 1295 2.16
LEGEND
Bhp -- Brake Horsepower
Low Range Motor/Drive Required
NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
