92
Table 46 — Fan Performance - 48PDF05 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 520 0.17 628 0.24 723 0.33 811 0.41 892 0.51
1300 545 0.20 648 0.28 739 0.37 823 0.46 902 0.56
1400 570 0.24 668 0.32 756 0.41 837 0.51 913 0.61
1500 596 0.28 691 0.37 775 0.46 853 0.56 927 0.67
1600 623 0.32 714 0.42 795 0.52 870 0.62 942 0.73
1700 650 0.37 737 0.48 816 0.58 889 0.69 958 0.80
1800 677 0.43 762 0.54 838 0.65 909 0.76 976 0.88
1900 705 0.50 787 0.61 861 0.72 929 0.84 994 0.97
2000 734 0.57 813 0.68 884 0.80 951 0.93 1014 1.06
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 968 0.61 1040 0.71 1108 0.82 1172 0.93 1233 1.04
1300 976 0.66 1046 0.77 1112 0.88 1176 1.00 1237 1.11
1400 985 0.72 1054 0.83 1119 0.95 1181 1.07 1241 1.19
1500 996 0.78 1063 0.90 1127 1.02 1188 1.14 1247 1.27
1600 1009 0.85 1074 0.97 1136 1.09 1196 1.22 1254 1.35
1700 1024 0.92 1087 1.05 1147 1.17 1205 1.31 1262 1.44
1800 1039 1.00 1100 1.13 1159 1.26 1216 1.40 1272 1.54
1900 1056 1.09 1116 1.22 1173 1.36 1229 1.50 1283 1.64
2000 1074 1.19 1132 1.32 1188 1.46 1242 1.61 1295 1.75
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
Table 47 — Fan Performance - 48PDD06 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 593 0.27 688 0.37 773 0.46 851 0.56 925 0.67
1600 620 0.32 711 0.42 793 0.52 868 0.62 939 0.73
1700 646 0.37 734 0.47 813 0.58 886 0.69 955 0.80
1800 673 0.43 758 0.53 835 0.64 905 0.76 972 0.88
1900 700 0.49 783 0.60 857 0.72 925 0.84 990 0.96
2000 728 0.56 807 0.68 879 0.80 946 0.92 1009 1.05
2100 755 0.63 833 0.76 903 0.88 968 1.01 1029 1.14
2200 783 0.71 858 0.84 926 0.97 990 1.11 1050 1.24
2300 811 0.80 884 0.94 950 1.07 1012 1.21 1071 1.35
2400 840 0.90 910 1.04 975 1.18 1035 1.33 1092 1.47
2500 868 1.00 937 1.15 1000 1.30 1059 1.45 1115 1.60
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 995 0.78 1061 0.89 1125 1.01 1186 1.14 1245 1.26
1600 1007 0.85 1072 0.96 1134 1.09 1194 1.22 1252 1.35
1700 1021 0.92 1084 1.04 1145 1.17 1203 1.30 1260 1.44
1800 1036 1.00 1098 1.13 1157 1.26 1214 1.39 1269 1.53
1900 1053 1.08 1112 1.22 1170 1.35 1226 1.49 1280 1.63
2000 1070 1.18 1128 1.31 1184 1.45 1238 1.60 1291 1.74
2100 1088 1.28 1145 1.42 1199 1.56 1253 1.71 1304 1.86
2200 1107 1.38 1162 1.53 1216 1.68 1268 1.83 1318 1.98
2300 1127 1.50 1181 1.65 1233 1.80 1284 1.95 1333 2.11
2400 1147 1.62 1200 1.77 1251 1.93 1300 2.09 1349 2.25
2500 1168 1.75 1220 1.91 1270 2.07 1318 2.23 1365 2.40
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
