APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)

Table 33 — MODE - OUTPUTS

ITEM

EXPANSION

RANGE

UNITS

CCN TABLE/SUB---TABLE

CCN POINT

CCN

WRITE

STATUS

DISPLAY

WRITE

STATUS

STATUS DISPLAY

OUTPUTS

UOUTPUT

FANS

Fan Outputs

IDF

Indoor Fan VFD Pwr Relay

On/Off

IDF

F.SPD

Commanded Fan Speed

xxx

%

FANSPEED

OFC.1

Outdoor Fan 1 Relay

On/Off

OFC_1

COOL

Cool Outputs

CTLR

Digital Scroll Ctrl Pwr

On/Off

COMPCTLR

CAPC

Compressor Capacity

xxx

%

CAPACITY

CCH

Crankcase Heat Relay

On/Off

CCH

HEAT

Heat Outputs

HT.1

Heat Stage 1 Relay

On/Off

HEAT_1

HT.2

Heat Stage 2 Relay

On/Off

HEAT_2

ECON

Economizer Outputs

EC.CP

Econo Commanded Position

0 to 100

%

ECONOCMD

forcible

forcible

EC.AP

Econo Actual Position

0 to 100

%

ECONOPOS

PE.1

Power Exhaust 1 Relay

On/Off

PE_1

forcible

forcible

PE.2

Power Exhaust 2 Relay

On/Off

PE_2

forcible

forcible

ALRM

Alarm Relay

On/Off

ALMOUT

forcible

forcible
