80
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 37 — MODE - OPERATING MODES (cont)
ITEM EXPANSION RANGE UNITS
CCN
TABLE/SUB---TABLE
CCN POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
(OCCDEFM = CCN only) Occupancy Supervisory OCCDEFM
Current Mode (1=Occup) 0,1 MODE
Current Occup Period # 0 to 8 PER_NO
Time--- Override in Effect Yes/No OVERLAST
Time--- Override Duration 0 to 4 hours OVR_HRS
Current Occupied Time xx.xx hh:mm STRTTIME
Current Unoccupied Time xx.xx hh:mm ENDTIME
Next Occupied Day NXTOCDAY
Next Occupied Time xx.xx hh:mm NXTOCTIM
Next Unoccupied Day NXTUNDAY
Next Unoccupied Time xx.xx hh:mm NXTUNTIM
Previous Unoccupied Day PRVUNDAY
Previous Unoccupied Time xx.xx hh.mm PRVUNTIM
(LINKDATA = CCN only) CCN --- Linkage LINKDATA
Supervisory Element # xxx SUPE--- ADR
Supervisory Bus xxx SUPE--- BUS
Supervisory Block Number xxx BLOCKNUM
Average Occup. Heat Stp. xxxx.x dF AOHS
Average Occup. Cool Stp. xxxx.x dF AOCS
Average Unocc. Heat Stp. xxxx.x dF AUHS
Average Unocc. Cool Stp. xxxx.x dF AUCS
Average Zone Temperature xxxx.x dF AZT
Average Occup. Zone Temp xxxx.x dF AOZT
Linkage System Occupied? Yes/No LOCC
Next Occupied Day ”Mon”, ”Tue”,
& , ”Sun”
3--- cha
r text
LNEXTOCD
Next Occupied Time xx:xx hh:mm LNEXTOCC forcible
Next Unoccupied Day ”Mon”, ”Tue”,
& , ”Sun”
3--- cha
r text
LNEXTUOD
Next Unoccupied Time xx:xx hh:mm LNEXTUNC forcible
Last Unoccupied Day ”Mon”, ”Tue”,
& , ”Sun”
3--- cha
r text
LLASTUOD
Last Unoccupied Time xx:xx hh:mm LLASTUNC forcible
Table 38 — MODE - ALARMS
ITEM EXPANSION RANGE DEFAULT
CCN
TABLE/SUB---TABLE
CCN POINT
CCN WRITE
STATUS
DISPLAY
WRITE
STATUS
MAINTENANCE
DISPLAY
ALARMS ALARMS
R.CUR Reset All Current Alarms Yes/No No ALRESET forcible forcible
R.HIS Reset Alarm History Yes/No No ALHISCLR forcible forcible
CURR Currently Active Alarms
alarm# text string ALARM01C ---
ALARM25C
(repeat up to 25
alarms)
HIST Alarm History ALARM HISTORY
alarm# alarm#--- mm/dd/yy--- hh.mm
--- text string
(repeat up to 20
Alarms)
