background image

36

Table 13 — IGC Board LED Alarm Codes

LED

FLASH

CODE

DESCRIPTION

ACTION TAKEN BY

CONTROL

RESET METHOD

PROBABLE CAUSE

On

Normal Operation

Off

Hardware Failure

No gas heating.

Loss of power to the IGC. Check 5 amp fuse on

IGC, power to unit, 24V circuit breaker, transformer,

and wiring to the IGC.

1 Flash

Indoor Fan On/Off Delay

Modified

5 seconds subtracted from

On delay.

5 seconds added to Off

delay (3 min max).

Power reset.

High temperature limit switch opens during heat

exchanger warm-up period before fan-on delay

expires.

High temperature limit switch opens within

10 minutes of heat call (W) Off.

See Limit Switch Fault.

2 Flashes Limit Switch Fault

Gas valve and igniter Off.

Indoor fan and inducer On.

Limit switch closed, or

heat call (W) Off.

High temperature limit switch is open. Check the

operation of the indoor (evaporator) fan motor.

Ensure that the supply-air temperature rise is within

the range on the unit nameplate. Check wiring and

limit switch operation.

3 Flashes Flame Sense Fault

Indoor fan and inducer On. Flame sense normal.

Power reset for LED reset.

The IGC sensed a flame when the gas valve should

be closed. Check wiring, flame sensor, and gas

valve operation.

4 Flashes Four Consecutive Limit Switch

Fault

No gas heating.

Heat call (W) Off.

Power reset for LED reset.

4 consecutive limit switch faults within a single call

for heat. See Limit Switch Fault.

5 Flashes Ignition Fault

No gas heating.

Heat call (W) Off.

Power reset for LED reset.

Unit unsuccessfully attempted ignition for 15 minutes.

Check igniter and flame sensor electrode spacing,

gaps, etc. Check flame sense and igniter wiring.

Check gas valve operation and gas supply.

6 Flashes Induced Draft Motor Fault

If heat off: no gas heating.

If heat on: gas valve Off

and inducer On.

Inducer sense normal, or

heat call (W) Off.

Inducer sense On when heat call Off, or inducer

sense Off when heat call On. Check wiring, voltage,

and operation of IGC motor. Check speed sensor

wiring to IGC.

7 Flashes Rollout Switch Lockout

Gas valve and igniter Off.

Indoor fan and inducer On.

Power reset.

Rollout switch has opened. Check gas valve

operation. Check induced-draft blower wheel is

properly secured to motor shaft.

8 Flashes Internal Control Lockout

No gas heating.

Power reset.

IGC has sensed internal hardware or software error.

If fault is not cleared by resetting 24 v power,

replace the IGC.

9 Flashes Temporary Software Lockout

No gas heating.

1 hour auto reset, or

power reset.

Electrical interference is disrupting the IGC

software.

LEGEND
IGC -- Integrated Gas Unit Control
LED -- Light--Emitting Diode
NOTES:
1. There is a 3--second pause between alarm code displays.
2. If more than one alarm code exists, all applicable alarm codes will be displayed in numerical sequence.

3. Alarm codes on the IGC will be lost if power to the unit is interrupted.

Table 14 — Electric Heat Service Analysis

PROBLEM

CAUSE

REMEDY

Heat Will Not Turn On.

Unit is not configured for heat.

Check heating configurations using ComfortLinkt

Scrolling Marquee.

Active alarm.

Check active alarms using

ComfortLink™ Scrolling

Marquee.

No power to unit.

Check power supply, fuses, wiring, and circuit breakers.

Unit is in minimum heat off---time, or minimum

cool---heat changeover time.

Check using

ComfortLinkt Scrolling Marquee.

Heat forced off in Service Test.

Check using

ComfortLinkt Scrolling Marquee. Turn

Service Test mode off.

No 24 vac at heater contactor.

Check transformer, circuit breaker, auto---reset limit

switches on heater, and manual---reset limit switches (LS)

on indoor fan housing.

Open temperature limit switch on heater.

Check minimum airflow. Check limit switch when it is cool,

replace if not.

Inadequate Heating.

Dirty air filters.

Replace air filters.

Bad heater elements.

Power off unit and remove high voltage wires. Check

resistance of element, replace if open.

Occupancy schedule set point set too low.

Check setpoints and adjust if necessary.

Heat undersized for load.

Decrease load or increase size of heater.

Restricted or low airflow.

Remove restriction, verify proper fan speed operation, and

check SAT compared to the SAT heating limits.

Too much outdoor air.

Check economizer position and configuration. Adjust

minimum position if needed using ComfortLinkt Scrolling

Marquee. Verify proper fan speed operation.

Limit switch cycles heaters.

Check rotation of blower, temperature rise of unit, and

minimum airflow. Adjust as needed.

Heat Will Not Turn Off.

Unit is in minimum heat on---time.

Check using

ComfortLinkt Scrolling Marquee.

Occupancy schedule set point still calling for

Heating.

Check using

ComfortLinkt Scrolling Marquee.

Unit running in Service Test mode.

Check using

ComfortLinkt Scrolling Marquee.

Heater contactor failed.

Power off unit. Check contactor and replace if closed.

LEGEND
SAT

--

Supply Air Temperature
