Carrier 48/50PD05 - Manual (Page 96)

96
Table 54 — Fan Performance - 48PDE06 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 536 0.23 640 0.32 729 0.41 811 0.51 887 0.61
1600 563 0.27 663 0.36 749 0.46 828 0.56 901 0.67
1700 590 0.31 686 0.42 770 0.52 846 0.62 917 0.74
1800 619 0.37 711 0.47 792 0.58 866 0.69 935 0.81
1900 648 0.43 737 0.54 816 0.65 887 0.77 954 0.89
2000 678 0.49 764 0.61 840 0.73 909 0.85 975 0.98
2100 709 0.56 792 0.69 865 0.81 933 0.94 996 1.07
2200 740 0.65 820 0.78 891 0.91 957 1.04 1019 1.17
2300 772 0.73 849 0.87 918 1.01 982 1.14 1042 1.28
2400 804 0.83 879 0.97 946 1.12 1008 1.26 1066 1.40
2500 837 0.94 909 1.09 974 1.24 1034 1.38 1092 1.53
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 958 0.72 1027 0.83 1092 0.95 1154 1.07 1214 1.20
1600 971 0.78 1037 0.90 1101 1.02 1162 1.15 1221 1.28
1700 985 0.85 1049 0.97 1111 1.10 1171 1.23 1228 1.36
1800 1001 0.93 1063 1.05 1124 1.18 1182 1.32 1238 1.45
1900 1018 1.01 1079 1.14 1138 1.27 1194 1.41 1249 1.55
2000 1036 1.10 1096 1.24 1153 1.37 1208 1.51 1262 1.66
2100 1056 1.20 1114 1.34 1170 1.48 1224 1.63 1276 1.78
2200 1077 1.31 1134 1.45 1188 1.60 1241 1.75 1292 1.90
2300 1099 1.43 1154 1.57 1207 1.72 1259 1.88 1309 2.03
2400 1122 1.55 1176 1.70 1228 1.86 1278 2.02 1327 2.18
2500 1146 1.69 1198 1.84 1249 2.00 1298 2.16 1346 2.33
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
Table 55 — Fan Performance - 48PDF06 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 551 0.24 653 0.33 741 0.42 821 0.52 896 0.62
1600 579 0.28 676 0.38 761 0.48 839 0.58 912 0.69
1700 608 0.33 701 0.43 783 0.54 858 0.64 929 0.76
1800 638 0.39 727 0.49 807 0.60 879 0.71 948 0.83
1900 668 0.45 755 0.56 831 0.68 902 0.79 968 0.91
2000 700 0.52 783 0.64 857 0.76 925 0.88 990 1.01
2100 732 0.60 812 0.72 884 0.85 950 0.97 1013 1.11
2200 765 0.68 842 0.81 912 0.95 976 1.08 1037 1.21
2300 799 0.78 873 0.92 940 1.05 1002 1.19 1062 1.33
2400 833 0.88 904 1.03 969 1.17 1030 1.31 1087 1.46
2500 867 1.00 936 1.15 999 1.30 1058 1.44 1114 1.60
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 968 0.73 1035 0.85 1100 0.97 1162 1.09 1222 1.21
1600 981 0.80 1047 0.92 1110 1.04 1171 1.16 1229 1.29
1700 996 0.87 1060 0.99 1121 1.12 1181 1.25 1238 1.38
1800 1013 0.95 1075 1.08 1135 1.21 1193 1.34 1248 1.48
1900 1031 1.04 1092 1.17 1150 1.30 1206 1.44 1261 1.58
2000 1051 1.14 1110 1.27 1166 1.41 1221 1.55 1275 1.69
2100 1072 1.24 1129 1.38 1185 1.52 1238 1.67 1290 1.82
2200 1094 1.35 1150 1.50 1204 1.64 1256 1.79 1307 1.95
2300 1118 1.48 1172 1.62 1225 1.77 1275 1.93 1325 2.09
2400 1142 1.61 1195 1.76 1246 1.92 1296 2.07 1344 2.24
2500 1168 1.75 1219 1.91 1269 2.07 1317 2.23 1365 2.40
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
48/
50P
D
