Table 52 — Fan Performance - 48PDF05 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 456 0.13 574 0.20 675 0.28 766 0.37 850 0.46
1300 477 0.16 591 0.23 688 0.32 776 0.41 857 0.50
1400 500 0.18 610 0.27 703 0.36 788 0.45 867 0.55
1500 524 0.22 630 0.31 720 0.40 802 0.50 879 0.60
1600 550 0.26 652 0.35 739 0.45 819 0.55 893 0.66
1700 576 0.30 675 0.40 759 0.50 836 0.61 908 0.72
1800 604 0.35 699 0.46 781 0.57 856 0.68 925 0.79
1900 633 0.41 724 0.52 804 0.63 876 0.75 944 0.87
2000 662 0.47 750 0.59 828 0.71 898 0.83 964 0.95
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 929 0.56 1003 0.66 1073 0.76 1139 0.87 1202 0.98
1300 934 0.60 1006 0.71 1075 0.82 1140 0.93 1202 1.05
1400 941 0.65 1012 0.76 1079 0.87 1143 0.99 1204 1.11
1500 951 0.71 1020 0.82 1085 0.94 1148 1.06 1208 1.18
1600 963 0.77 1029 0.89 1093 1.01 1155 1.13 1214 1.26
1700 976 0.84 1041 0.96 1103 1.08 1163 1.21 1221 1.34
1800 991 0.91 1054 1.04 1115 1.16 1174 1.30 1230 1.43
1900 1008 0.99 1070 1.12 1129 1.25 1186 1.39 1241 1.53
2000 1026 1.08 1086 1.21 1144 1.35 1199 1.49 1253 1.63
LEGEND
Bhp -- Brake Horsepower
High Range Motor/Drive Required
NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
Table 53 — Fan Performance - 48PDD06 Horizontal Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 521 0.22 628 0.31 718 0.40 800 0.49 877 0.60
1600 546 0.25 649 0.35 737 0.45 816 0.55 890 0.65
1700 572 0.30 671 0.40 757 0.50 834 0.61 906 0.72
1800 599 0.35 695 0.45 777 0.56 852 0.67 922 0.79
1900 627 0.40 719 0.51 799 0.63 872 0.74 940 0.86
2000 655 0.46 745 0.58 822 0.70 893 0.82 959 0.94
2100 684 0.53 771 0.66 846 0.78 915 0.91 979 1.03
2200 714 0.61 797 0.74 871 0.87 938 1.00 1001 1.13
2300 744 0.69 824 0.83 896 0.96 961 1.10 1022 1.24
2400 775 0.78 852 0.92 922 1.06 985 1.21 1045 1.35
2500 806 0.88 880 1.03 948 1.18 1010 1.32 1069 1.47
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 949 0.70 1018 0.82 1083 0.93 1146 1.05 1207 1.18
1600 961 0.77 1027 0.88 1091 1.00 1153 1.13 1212 1.26
1700 974 0.83 1039 0.95 1101 1.08 1161 1.21 1219 1.34
1800 988 0.91 1052 1.03 1112 1.16 1171 1.29 1227 1.43
1900 1004 0.99 1066 1.11 1125 1.25 1182 1.38 1238 1.52
2000 1022 1.07 1082 1.20 1139 1.34 1195 1.48 1249 1.62
2100 1040 1.17 1099 1.30 1155 1.44 1209 1.59 1262 1.73
2200 1060 1.27 1117 1.41 1172 1.55 1225 1.70 1277 1.85
2300 1081 1.38 1136 1.52 1190 1.67 1242 1.82 1292 1.98
2400 1102 1.50 1156 1.65 1209 1.80 1259 1.96 1309 2.12
2500 1124 1.62 1177 1.78 1228 1.94 1278 2.10 1326 2.26
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
