73
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 34 — MODE - CONFIGURATION
ITEM EXPANSION RANGE UNITS DEFAULT
CCN
TABLE/SUB---TABLE
CCN POINT
PAGE
NO.
CONFIGURATION SERVICE
CONFIGURATION
DISP Display Configuration DISPLAY
METR Metric Display On/Off Off DISPUNIT 11
LANG Language Selection 0=English
1=Spanish
2=French
3=Portuguese
0 LANGUAGE 11
PROT Password Enable Enable/Disable Disable PASS_EBL 12
PSWD Service Password 0000 to 9999 1111 PASSWORD 12
TEST Test Display LEDs On/Off Off (display only, not in
table)
DISPTEST 12
UNIT Unit Configuration UNIT
S.DLY Startup Delay 0 to 600 sec 30 STARTDLY 12
OC.FN Fan On When Occupied Yes/No Yes OCC_FAN 12
IDF.F Shut Down on IDF Failure Yes/No Yes FATALFAN 12
FS.MX Supply Fan Maximum
Speed
80 to 100 % 100 SPEEDMAX 12
FS.MN Supply Fan Minimum
Speed
10 to 40 % 20 SPEEDMIN 12
FS.VM Vent Mode Fan Speed 40 to 100 ^F 50 SPEEDVNT 12
FN.SW Fan Status Switch 0=No Switch
1=Normal Open
2=Normal Closed
0: no FIOP
1: FIOP
FANSTCFG 12
FL.SW Filter Status Switch 0=No Switch
1=Normal Open
2=Normal Closed
0: no FIOP
1: FIOP
FILSTCFG 12
FS.SW Fire Shutdown Switch 0=No Switch
1=Normal Open
2=Normal Closed
0: no FIOP
1: FIOP
SHTDNCFG 12
RM.SW Remote Occupancy
Switch
0=No Switch
1=Normal Open
2=Normal Closed
0 REMOCCFG 12
RH.S RH Sensor on OAQ Input Yes/No No RH_OAQ 13
RH.SW Space Humidity Switch 0=No Switch
1=Normal Open
2=Normal Closed
0 HUMSTCFG 13
TCS.C Temp Cmp Strt Cool Factr 0 to 60 mins 0 TCSTCOOL 13
TCS.H Temp Cmp Strt Heat Factr 0 to 60 mins 0 TCSTHEAT 13
COOL Cooling Configuration COOL_CFG
MIN.C Min Compressor Capacity 15 to 80 % 70 MIN_CAPC 14
FS.CD Fan Speed Control
Demand
1 to 9.9 ^F 3 SPEEDDMD 17
MRT.C Compressor Min On Time 120 to 999 sec 180 MIN_ON
MOT.C Compressor Min Off Time 300 to 999 sec 300 MIN_OFF
RST.C Runtime to Reset Strikes 120 to 999 sec 300 MIN_ON_S 24
FOD.C Fan-off Delay, Mech Cool 0 to 600 sec 60 COOL_FOD
CS.A1 Current Sensing A1 Enable/Disable Disable: reserved for
future use
DO NOT ENABLE
A1_SENSE 25
C.LO Compressor Lockout
Temp
0 to 100F dF 0 OATLCOMP
ALM.N Alert Each Strike Yes//No Yes ALM_NOW 24
SAT Supply Air Temperature
SASP Cool Supply Air Setpoint 45 to 75 dF 65 SASP 17
SA.MU SASP Maximum Reset Up 0 to 20 ^F 10 SASPMAXU 18
SA.MD SASP Maximum Reset
Down
--- 20 to 0 ^F --- 10 SASPMAXD 18
SAT.U Minimum SAT Upper Level 35.0 to 65.0 dF 60 SATMIN_H
SAT.L Minimum SAT Lower Level 35.0 to 65.0 dF 45 SATMIN_L
SST Low Suction Control
SST.O Suction OK Temperature 10 to 50 dF 18 SSTOK 26
SST.1 Low Suction --- Level 1 10 to 50 dF 20 SSTLEV1 26
SST.2 Low Suction --- Level 2 5 to 50 dF 15 SSTLEV2 26
SST.3 Low Suction --- Level 3 0 to 50 dF 10 SSTLEV3 26
PSI.D Ckt A Minimum Pressure 0 to 500 psig 20 DELTAP_A 26
OFC Outdoor Fan Control
1.MXP Fan Lev1 Max Pressure 100 to 500 psig 450 LEV1MAXP 15
2.MNP Fan Lev2 Min Pressure 100 to 500 psig 200 LEV2MINP 15
2.ON Fan Lev2 On Temperature 0 to 100 F 55 LEV2ON 15
2.OFF Fan Lev2 Off Temperature 0 to 100 F 45 LEV2OFF 15
