Table 17 — Temperature vs Resistance Values for the DTT Thermistor
(86K at 25_C Resistors)
Degree C Degree F Resistance (k Ohms)
---40 ---40 2889.60
---35 ---31 2087.22
---30 ---22 1522.20
---25 ---13 1121.44
---20 ---4 834.72
---15 5 627.28
---10 14 475.74
---5 23 363.99
0 32 280.82
5 41 218.41
10 50 171.17
15 59 135.14
20 68 107.44
25 77 86.00
30 86 69.28
35 95 56.16
40 104 45.81
45 113 37.58
50 122 30.99
55 131 25.68
60 140 21.40
65 149 17.91
Degree C Degree F Resistance (k Ohms)
70 158 15.07
75 167 12.73
80 176 10.79
85 185 9.20
90 194 7.87
95 203 6.77
100 212 5.85
105 221 5.09
110 230 4.45
115 239 3.87
120 248 3.35
125 257 2.92
130 266 2.58
135 275 2.28
140 284 2.02
145 293 1.80
150 302 1.59
155 311 1.39
160 320 1.25
165 329 1.12
170 338 1.01
175 347 0.92
180 356 0.83
