70
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 28 — MODE - SERVICE TEST
ITEM EXPANSION RANGE UNITS DEFAULT CCN TABLE/SUB---TABLE CCN POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
SERVICE TEST MAINTENANCE DISPLAY
TEST Field Service Test Mode On/Off Off (TEST = display only) MAN_CTRL forcible forcible
INDP Test Independent Outputs TESTINDP
ECON Economizer Position Test 0 to 100 % 0 S_ECONO forcible forcible
E.CAL Calibrate Economizer On/Off Off S_ECOCAL forcible forcible
PE.1 Power Exhaust 1 Test On/Off Off S_PE_1 forcible forcible
PE.2 Power Exhaust 2 Test On/Off Off S_PE_2 forcible forcible
ALRM Alarm Relay Test On/Off Off S_ALMOUT forcible forcible
CCH Crankcase Heat Test On/Off Off S_CCH forcible forcible
FANS Test Fans TESTFANS
IDF Supply VFD Power Test On/Off Off S_IDF forcible forcible
F.SPD Indoor Fan Speed Test 0 to 100 % 0 S_VSPEED forcible forcible
OFC.1 Outdoor Fan Relay Test On/Off Off S_OFC_1 forcible forcible
COOL Test Cooling TESTCOOL
CTLR Dig Scroll Ctrl Pwr Test On/Off Off S_CMPCTL forcible forcible
CAPC Compressor Capacity Test 0 to 100 % 0 S_VCAP forcible forcible
F.SPD Cool Test Fan Speed 0 to 100 % 0 S_VSPDCL forcible forcible
HEAT Test Heating TESTHEAT
HT.1 Heat Stage 1 Test On/Off Off S_HEAT_1 forcible forcible
HT.2 Heat Stage 2 Test On/Off Off S_HEAT_2 forcible forcible
Table 29 — MODE - TEMPERATURES
ITEM EXPANSION RANGE UNITS CCN TABLE/SUB---TABLE CCN POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
STATUS DISPLAY
TEMPERATURES UINPUT
AIR.T Air Temperatures
SAT Supply Air Temperature xxx.x dF SAT_DISP
OAT Outdoor Air Temperature xxx.x dF OA_TEMP forcible forcible
SPT Space Temperature xxx.x dF SPACE_T forcible forcible
SPTO Space Temperature Offset xxx.x dF SPTO forcible forcible
RAT Return Air Temperature xxx.x dF RETURN_T forcible forcible
REF.T Refrigerant Temperatures xxx.x dF
SST.A Sat. Suction Temp A xxx.x dF SST_A
SCT.A Sat. Condenser Temp A xxx.x dF SCT_A
Table 30 — MODE - PRESSURES
ITEM EXPANSION RANGE UNITS CCN TABLE/SUB---TABLE CCN POINT
CCN
WRITE
STATUS
STATUS DISPLAY
PRESSURES UINPUT
SSP.A Suction Pressure A xxx.x psig SSP_A
SCP.A Condenser Pressure A xxx.x psig SCP_A
