Carrier 48/50PD05 - Manual (Page 97)

97
Table 56 — Fan Performance - 50PD05 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 492 0.15 604 0.22 701 0.31 790 0.39 873 0.49
1300 513 0.18 620 0.26 714 0.34 800 0.43 880 0.53
1400 534 0.21 638 0.29 729 0.38 812 0.48 889 0.58
1500 557 0.24 657 0.33 745 0.43 825 0.53 900 0.63
1600 580 0.28 677 0.38 762 0.48 839 0.58 912 0.69
1700 603 0.33 697 0.43 779 0.53 855 0.64 926 0.75
1800 627 0.38 718 0.48 798 0.59 871 0.70 940 0.82
1900 651 0.43 739 0.54 817 0.65 889 0.77 956 0.89
2000 675 0.49 761 0.61 837 0.72 907 0.85 972 0.97
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1200 950 0.58 1023 0.69 1092 0.79 1157 0.90 1219 1.02
1300 955 0.63 1027 0.74 1094 0.85 1158 0.96 1220 1.08
1400 962 0.68 1032 0.79 1098 0.91 1161 1.03 1222 1.15
1500 971 0.74 1039 0.85 1103 0.97 1165 1.09 1225 1.22
1600 981 0.80 1047 0.92 1110 1.04 1171 1.17 1229 1.30
1700 993 0.87 1057 0.99 1118 1.11 1178 1.24 1235 1.38
1800 1005 0.94 1068 1.06 1128 1.19 1186 1.33 1242 1.46
1900 1019 1.02 1080 1.14 1139 1.28 1196 1.41 1251 1.56
2000 1034 1.10 1094 1.23 1151 1.37 1206 1.51 1260 1.65
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
Table 57 — Fan Performance -- 50PD06 Vertical Units
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 568 0.25 667 0.34 753 0.44 833 0.54 908 0.64
1600 592 0.29 687 0.39 771 0.49 848 0.59 920 0.70
1700 616 0.34 708 0.44 789 0.54 864 0.65 934 0.76
1800 641 0.39 730 0.50 809 0.61 881 0.72 950 0.83
1900 665 0.45 752 0.56 829 0.67 900 0.79 966 0.91
2000 690 0.51 775 0.63 850 0.75 918 0.87 983 0.99
2100 716 0.57 798 0.70 871 0.82 938 0.95 1001 1.08
2200 742 0.65 821 0.78 892 0.91 958 1.04 1020 1.18
2300 768 0.73 845 0.86 915 1.00 979 1.14 1039 1.28
2400 794 0.81 869 0.96 937 1.10 1000 1.24 1059 1.38
2500 820 0.91 894 1.05 960 1.20 1021 1.35 1079 1.50
AIRFLOW
(Cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1500 978 0.75 1046 0.87 1110 0.98 1172 1.11 1231 1.23
1600 989 0.81 1055 0.93 1117 1.05 1178 1.18 1236 1.31
1700 1001 0.88 1065 1.00 1126 1.13 1185 1.26 1242 1.39
1800 1015 0.96 1077 1.08 1136 1.21 1194 1.35 1250 1.48
1900 1029 1.04 1090 1.16 1148 1.30 1204 1.44 1259 1.58
2000 1045 1.12 1104 1.26 1161 1.39 1216 1.53 1269 1.68
2100 1061 1.21 1119 1.35 1174 1.49 1228 1.64 1280 1.79
2200 1078 1.31 1135 1.45 1189 1.60 1241 1.75 1293 1.90
2300 1096 1.42 1151 1.57 1204 1.71 1256 1.87 1306 2.02
2400 1115 1.53 1169 1.68 1221 1.84 1271 1.99 1320 2.15
2500 1134 1.65 1187 1.81 1238 1.97 1287 2.13 1335 2.29
LEGEND
Bhp -- Brake Horsepower NOTES:
1. Maximum continuous BHP is 2.0.
2. See General Fan Performance Notes.
