82
APPENDIX B - VFD INFORMATION (CONT)
Table 40 — VFD CONFIGURATIONS
APPLICATION CRITICAL DRIVE PARAMETERS FOR ABB ACH550 DRIVES
Parameter Group
Parameter
Number
Description
Value
UNITS NOTE
HK30WA001---208/230V HK30WA008---460V
START---UP
DATA
9901 Language (0) English --- ABB Drive default
9902 Application Macro (1) HVAC Default ---
PD Product specific
setting
9904 Motor Control Mode (3) Scalar : Freq --- ABB Drive default
9905 Motor Nominal Voltage 230 460 Volts
PD Product specific
setting
9906 Motor Nominal Current 7.0 3.5 Amps
PD Product specific
setting
9907 Motor Nominal Frequency 60 Hz ABB Drive default
9908 Motor Nominal Speed 1725 RPM
PD Product specific
setting
9909 Motor Nominal Power 2.4 HP
PD Product specific
setting
START/STOP/DIR
1001 EXT1 Commands (1) DI --- 1 Start/Stop --- ABB Drive default
1002 EXT2 Commands (1) DI --- 1 Start/Stop --- ABB Drive default
1003 Direction (1) Forward ---
PD Product specific
setting
ANALOG INPUTS
1301 Minimum Al --- 1 20 % ABB Drive default
1302 Maximum Al --- 1 100 % ABB Drive default
RELAY OUTPUTS
1401 Relay Output 1 (7) Started ---
Carrier default settings
from PPS
1402 Relay Output 2 (2) Run --- ABB Drive default
1403 Relay Output 3 (3) Fault (---1) --- ABB Drive default
SYSTEM
CONTROL
1601 Run Enable (0) Not Set --- ABB Drive default
1608 Start Enable 1 (4) DI --- 4 --- ABB Drive default
OVER RIDE
1701 Override Set (3) DI --- 3 ---
Carrier default settings
from PPS
1702 Override Freq 60 Hz
Carrier default settings
from PPS
1703 Override Speed 1750 RPM
Carrier default settings
from PPS
1704 Over Pass Code 0 ---
Carrier default settings
from PPS
1705 Override On ---
Carrier default settings
from PPS
LIMITS
2003 Maximum Current 8.0 4.0 Amps
PD Product specific
setting
2007 Minimum Frequency 0 Hz ABB Drive default
2008 Maximum Frequency 60 Hz ABB Drive default
START/STOP
2101 Start Function (8) Ramp ---
PD Product specific
setting
2102 Stop Function (2) Ramp ---
PD Product specific
setting
ACCEL/DECEL
2202 Accelerate Time 30 Seconds ABB Drive default
2203 Decelerate Time 30 Seconds ABB Drive default
MOTOR
2601 Flux Optimization (1) On ---
PD Product specific
setting
2605 Volt/Freq Ratio (2) Squared ---
Carrier default settings
from PPS
2606 Switching Frequency 8 kHz
Carrier default settings
from PPS
FAULT
FUNCTIONS
3006 Motor Thermal Time 1050 Seconds
Carrier default settings
from PPS
All Other Parameter Settings are ABB Drive Default Settings
