76
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 34 — MODE - CONFIGURATION (cont)
ITEM EXPANSION RANGE UNITS DEFAULT
CCN
TABLE/SUB---TABLE
CCN POINT
PAGE
NO.
(GENERIC = CCN only) GENERICS 5
POINT 01 Definition 8--- char ASCII Point_01
POINT 02 Definition 8--- char ASCII Point_02
POINT 03 Definition 8--- char ASCII Point_03
POINT 04 Definition 8--- char ASCII Point_04
POINT 05 Definition 8--- char ASCII Point_05
POINT 06 Definition 8--- char ASCII Point_06
POINT 07 Definition 8--- char ASCII Point_07
POINT 08 Definition 8--- char ASCII Point_08
POINT 09 Definition 8--- char ASCII Point_09
POINT 10 Definition 8--- char ASCII Point_10
POINT 11 Definition 8--- char ASCII Point_11
POINT 12 Definition 8--- char ASCII Point_12
POINT 13 Definition 8--- char ASCII Point_13
POINT 14 Definition 8--- char ASCII Point_14
POINT 15 Definition 8--- char ASCII Point_15
POINT 16 Definition 8--- char ASCII Point_16
POINT 17 Definition 8--- char ASCII Point_17
POINT 18 Definition 8--- char ASCII Point_18
POINT 19 Definition 8--- char ASCII Point_19
POINT 20 Definition 8--- char ASCII Point_20
TRIM Sensor Calibration (CCN TRIM --- see
Maintenance
Display)
SPT.C Space Temp Calibration --- 30 to 130 dF 38
SPT.T Space Temp Trim --- 30 to 30 ^F 0 38
SAT.C Supply Air Temp Calib. --- 30 to 130 dF 38
SAT.T Supply Air Temp Trim --- 30 to 30 ^F 0 38
RAT.C Return Air Temp Calib. --- 30 to 130 dF 38
RAT.T Return Air Temp Trim --- 30 to 30 ^F 0 37
CONFIGURATION
CCN CCN Configuration 48_50_PD
CCN.A CCN Element Number 1 to 239 1 CCNADD 8
CCN.B CCN Bus Number 0 to 239 0 CCNBUS 8
BAUD CCN Baud Rate 2400, 4800, 9600,
19200, 38400
3 CCNBAUDD 8
BROD CCN Broadcast Config. BRODEFS
B.TIM CCN Time/Date Broadcast Yes/No No CCNBC 23
B.OAT CCN OAT Broadcast Yes/No No OATBC 23
B.GS Global Schedule Broadcst Yes/No No GSBC 23
B.ACK CCN Broadcast Ack’er Yes/No No CCNBCACK 23
SCH.O CCN Schedule Overrides SCHEDOVR
SCH.N Schedule Number 0 = Always
Occupied
1--- 64 =
Local Schedule
65--- 99
= Global Schedule
0 SCHEDNUM 23
HOL.G Accept Global Holidays Yes/No No HOLIDAYT 23
OV.TL Override Time Limit 0 to 4 hours 4 OTL 23
OV.EX Timed Override Hours 0 to 4 hours 0 OVR_EXT 23
OV.SP SPT Override Enabled Yes/No Yes TIMEOVER 23
LDSH CCN Schedule Overrides LOADSHED
S.GRP Loadshed Group Number 0 to 16 0 SHED_NUM 24
R.MXC Redline Max Capacity 0 to 100 % 100 MAXCREDL 24
S.MXC Loadshed Max Capacity 0 to 100 % 100 MAXCSHED
R.MXH Redline Max Heat Stages 0 to 2 2 MAXHREDL 24
S.MXH Loadshed Max Heat
Stages
0 to 2 2 MAXHSHED
