79
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 37 — MODE - OPERATING MODES (cont)
ITEM EXPANSION RANGE UNITS
CCN
TABLE/SUB---TABLE
CCN POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
HEAT Heat Mode Diagnostic HEATDIAG
HEAT In Heating Mode? Yes/No IN_HEAT
OK.HT OK to Select Heat Mode? Yes/No OKTOHEAT
MS.TG Mode Select Timeguard xxx secs HEATMSTG
H.LOC Heat OAT Lockout Yes/No HEATLOCK
HT.LO Heating Lockout Temp xxx dF OATLHEAT
IDF Indoor Fan State On/Off IDFSTATE
F.SPD Commanded Fan Speed xxx FANSPEED
AVL.H Available Heating Stages x AVLHSTGS
REQ.H Requested Heating Stages x REQHSTGS
LMT.H Max Heat Stage In Effect x HSTGLIMT
ACT.H Actual Heating Stages x ACTHSTGS
HT.1 Heat Stage 1 Relay On/Off HEAT_1
HT.2 Heat Stage 2 Relay On/Off HEAT_2
SAT Supply Air Temperature
SAT.H SAT Heat Mode Sensing Enable/Disable SAT_HEAT
SAT Supply Air Temperature xxx.x dF SAT_DISP
SAM.L Maximum SAT Lower Level xxx dF SATMAX_L
SAM.U Maximum SAT Upper Level xxx dF SATMAX_H
SPT Space Temperature
SPT Space Temperature xxx.x dF SPACE_T forcible
DMD.H Heating Demand xxx.x dF HEAT_DMD
TRND Spacetemp Trend (F/min) xxx.x SPTTREND
HT.PD SPT Heat Demand (+)
Level
xx.x ^F HDEM_POS
HT.ND SPT Heat Demand (--- )
Level
xx.x ^F HDEM_NEG
H.LAG Heat Thermal Lag Factor x.x min HEAT_LAG
ECON Economizer Diagnostic ECONDIAG
EC.EN Economizer Installed Yes/No ECONO
OCC Currently Occupied Yes/No OCCUPIED forcible forcible
IDF Indoor Fan State On/Off IDFSTATE
F.SPD Commanded Fan Speed NNN FANSPEED
COOL In Cooling Mode? Yes/No IN_COOL
E.LOC Econo Cool OAT Lockout Yes/No ECONLOCK
EH.LO Econo Cool Hi Temp Limit xxx dF OATLECLH
EL.LO Econo Cool Lo Temp Limit xx dF OATLECLL
FC.LO Free Cool Low Temp Limit xx dF OATLUEFC
EN.LO Econo Cool Enth Lockout Yes/No ENTHLOCK
EC.MX Econo Cool Max Position xxx % ECONOMAX
AQ.DV IAQ DCV Mode Yes/No IN_IAQDV
AQ.MN Econo Min IAQ Position xxx % IAQMINP
AQ.OV IAQ Override Mode Yes/No IN_IAQOV
OVR.P IAQ Override Position xxx % IAQOVPOS
AQ.LO OAQ Lockout Mode Yes/No IN_OAQLO
OAQ.L OAQ Lockout Limit xxxx OAQLOCK
LP.OV Lo Refrig Press Override Yes/No IN_LPOV
EC.CP Econo Commanded
Position
xxx % ECONOCMD forcible
EC.AP Econo Actual Position xxx % ECONOPOS
EC.MP Min Position in Effect xxx % MIN_POS forcible
C.ANG Actuator Control Angle CTLANGLE
E.CAL Economizer Calibrating Yes/No ECOINCAL
DMD.L Demand Limiting DMDL
D.LMT Demand Limit In Effect Yes/No MODEDMDL
LMT.C Max Capacity In Effect xxx CAPLIMIT
LMT.H Max Heat Stage In Effect x HSTGLIMT
REDL Redline Activated Yes/No MODEREDL
SHED Loadshed Activated Yes/No MODESHED
MAX.C Max Compressor Capacity x MAX_CAPC forcible
MAX.H Max Allowed Heat Stages x MAXHSTGS forcible
(Display TRIM --- see
Configuration)
Sensor Calibration TRIM
Space Temp Calibration --- 30 to 130 dF SPT_CAL forcible
Space Temp Trim --- 30 to 30 ^F SPT_OFF forcible
Supply Air Temp Calib. --- 30 to 130 dF SAT_CAL forcible
Supply Air Temp Trim --- 30 to 30 ^F SAT_OFF forcible
Return Air Temp Calib. --- 30 to 130 dF RAT_CAL forcible
Return Air Temp Trim --- 30 to 30 ^F RAT_OFF forcible
