71
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 31 — MODE - SET POINTS
ITEM EXPANSION RANGE UNITS DEFAULT CCN TABLE/SUB---TABLE CCN POINT
SETPOINT CONFIGURATION
SETPOINTS SET_PNT
OCSP Occupied Cool Setpoint 55 to 80F dF 78 OCSP
UCSP Unoccupied Cool Setpoint 75 to 95F dF 85 UCSP
OHSP Occupied Heat Setpoint 55 to 80F dF 68 OHSP
UHSP Unoccupied Heat Setpoint 40 to 80F dF 60 UHSP
GAP Heat--- Cool Setpoint Gap 2 to 10F ^F 5 HCSP_GAP
STO.R SPT Offset Range (+/--- ) 0 to 5F ^F 5 SPTO_RNG
SASP Cool Supply Air Setpoint 45 to 75 dF 65 SASP
RH.SP Space RH Setpoint 30 to 95 % 50 SPRH_SP
RH.DB Space RH Deadband 2 to 20 % 5 SPRH_DB
C.LO Compressor Lockout Temp 0 to 100F dF 0 OATLCOMP
HT.LO Heating Lockout Temp 40 to 125F dF 75 OATLHEAT
EH.LO Econo Cool Hi Temp Limit 40 to 100F dF 65 OATLECLH
EL.LO Econo Cool Lo Temp Limit --- 30 to 50F dF 0 OATLECLL
FC.LO Free Cool Low Temp Limit 0 to 70F dF 50 OATLUEFC
Table 32 — MODE -- INPUTS
ITEM EXPANSION RANGE UNITS CCN TABLE/SUB---TABLE
CCN
POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
STATUS DISPLAY
INPUTS UINPUTS
GEN.I General Inputs
FIL.S Filter Status Switch Dirty/Clean FILTSTAT forcible
FAN.S Fan Status Switch On/Off FAN_STAT forcible
FDWN Fire Shutdown Switch On/Off FIREDOWN forcible
ENTH Outdoor Enthalpy Switch High/Low ENTHALPY forcible
RM.OC Remote Occupancy Switch On/Off REM_OCC forcible
HUM Space Humidity Switch High/Low HUM_STAT forcible
CMP.A Compressor A Feedback On/Off COMP_A
C.ALM Scroll Compressor Alarm On/Off COMP_ALM
CS.IN Current Sensor Inputs
CS.A1 Compressor A1 Feedback On/Off CS_A1
AIR.Q Air Quality Inputs
IAQ.S IAQ Level (switch) High/Low IAQIN forcible forcible
IAQ IAQ Level (sensor) xxxx ppm IAQ forcible forcible
OAQ OAQ Level (sensor) xxxx ppm OAQ forcible forcible
SP.RH Space Humidity Sensor xxx.x % SPRH forcible forcible
