78
APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 37 — MODE - OPERATING MODES
ITEM EXPANSION RANGE UNITS
CCN
TABLE/SUB---TABLE
CCN POINT
CCN
WRITE
STATUS
DISPLAY
WRITE
STATUS
OPERATING MODES MAINTENANCE
DISPLAY
MODE Control Modes MODES
SYS Unit operation disabled
Unit operation enabled
Service test enabled
SYS_MODE_TEXT1
SYS_MODE_TEXT2
(table only)
SYS_MODE_TEXT3
(table only)
HVAC HVAC Operation Disabled
Ventilation (fan--- only)
Cooling
Unoccupied Free Cooling
Heating
HVACMODE_TEXT
_1
HVACMODE_TEXT
_2 (table only)
HVACMODE_TEXT
_3 (table only)
HV.DN Remote HVAC Mode
Disable
Yes/No HVACDOWN forcible
EFF.C Cool Setpoint in Effect xxx.x CSP_EFF
EFF.H Heat Setpoint in Effect xxx.x HSP_EFF
OCC Currently Occupied Yes/No OCCUPIED forcible forcible
T.OVR Timed Override in Effect Yes/No MODETOVR
LINK Linkage Active Yes/No MODELINK
D.LMT Demand Limit In Effect Yes/No MODEDMDL
C.LOC Compressor OAT Lockout Yes/No COMPLOCK
H.LOC Heat OAT Lockout Yes/No HEATLOCK
E.LOC Econo Cool OAT Lockout Yes/No ECONLOCK
COOL Cool Mode Diagnostic COOLDIAG
COOL In Cooling Mode? Yes/No IN_COOL
OK.CL OK to Select Cool Mode? Yes/No OKTOCOOL
MS.TG Mode Select Timeguard xxx secs COOLMSTG
OK.EC OK to Use Economizer? Yes/No ECONCOOL
OK.MC OK to Use Compressor? Yes/No MECHCOOL
C.LOC Compressor OAT Lockout Yes/No COMPLOCK
C.LO Compressor Lockout Temp xxx dF OATLCOMP
IDF Indoor Fan State On/Off IDFSTATE
F.SPD Commanded Fan Speed xxx FANSPEED
REQ.C Requested Cooling
Capacity
xxx % REQ_CAPC
MIN.C Min Compressor Capacity xxx % MIN_CAPC
MAX.C Max Compressor Capacity xxx % MAX_CAPC
LMT.C Max Capacity In Effect xxx % CAPLIMIT
CAPC Compressor Capacity xxx % CAPACITY
CTLR Digital Scroll Ctrl Pwr On/Off COMPCTLR
CMP.A Compressor A Feedback On/Off COMP_A
ST.A Circuit A Strikes x ASTRIKES
F.LEV Outdoor Fan Level x FANLEV
SAT Supply Air Temperature
SAT Supply Air Temperature xxx.x dF SAT_DISP
SA.DM Supply Air Temp Demand xxx.x ^F SAT_DMD
SAT.U Minimum SAT Upper Level xx.x dF SATMIN_H
SAT.L Minimum SAT Lower Level xx.x dF SATMIN_L
SPT Space Temperature
SPT Space Temperature xxx.x dF SPACE_T forcible
TRND Spacetemp Trend (F/min) xxx.x SPTTREND
DMD.C Cooling Demand xxx.x ^F COOL_DMD
