Table 65 — MODE - CONFIGURATION (cont)
ITEM
EXPANSION
RANGE
UNITS
DEFAULT
CCN
TABLE/SUB---TABLE
CCN POINT
ENTRY
AIR.Q
Air Quality Config.
IAQ_CFG
IA.CF
IAQ Analog Input Config
0=No IAQ
1=DCV
2=Override IAQ
3=Ctrl Min Pos
0: no FIOP
1: FIOP
IAQANCFG
IA.FN
IAQ Analog Fan Config
0=Never
1=Occupied
2=Always
0
IAQANFAN
II.CF
IAQ Switch Input Config
0=No IAQ
1=DCV N/O
2=DCV N/C
3=Override N/O
4=Override N/C
0
IAQINCFG
II.FN
IAQ Switch Fan Config
0=Never
1=Occupied
2=Always
0
IAQINFAN
AQ.MN
Econo Min IAQ Position
0 to 100
%
10
IAQMINP
OVR.P
IAQ Override Position
0 to 100
%
100
IAQOVPOS
OA.CF
OAQ Analog Input Config
0=No OAQ
1=DCV
2=Lockout OAQ
0
OAQANCFG
OAQ.L
OAQ Lockout Limit
0 to 5000
600
OAQLOCK
AQD.L
AQ Differential Low
0 to 5000
100
DAQ_LOW
AQD.H
AQ Differential High
0 to 5000
700
DAQ_HIGH
DF.ON
Fan On AQ Differential
0 to 5000
600
DAQFNON
DF.OF
Fan Off AQ Differential
0 to 5000
200
DAQFNOFF
I.4M
IAQ Sensor Value at 4mA
0 to 5000
0
IAQ_4MA
I.20M
IAQ Sensor Value at 20mA
0 to 5000
2000
IAQ_20MA
O.4M
OAQ Sensor Value at 4mA
0 to 5000
0
OAQ_4MA
O.20M
OAQ Sensor Value at
20mA
0 to 5000
2000
OAQ_20MA
H.4M
RH Sensor Value at 4mA
0 to 50
%
0
RH_4MA
H.20M
RH Sensor Value at 20mA
60 to 100
%
100
RH_20MA
ALM.O
Alarm Relay Config.
ALM_CFG
A.SPC
SPT/SPRH Sensor Failure
Yes/No
Yes
SPACE_AL
A.SRT
SAT/RAT Sensor Failure
Yes/No
Yes
SATRATAL
A.OAT
OAT Thermistor Failure
Yes/No
Yes
OAT_AL
A.CS
Current Sensor Failure
Yes/No
No
CS_AL
A.CMP
Compressor Failure
Yes/No
Yes
COMP_AL
A.CKT
Refrig Circuit Failure
Yes/No
Yes
CKT_AL
A.SSP
SSP Transducer Failure
Yes/No
Yes
SSP_AL
A.SCT
SCT Thermistor Failure
Yes/No
Yes
SCT_AL
A.FAN
Indoor Fan Failure
Yes/No
Yes
FAN_AL
A.FIL
Dirty Filter
Yes/No
Yes
FILT_AL
A.ECO
Economizer Failure
Yes/No
Yes
ECON_AL
PID
PID Configurations
PID_CFG
EC.P
Economizer PID --- kP
0.0 to 99.9
2.5
ECONO_P
EC.I
Economizer PID --- kI
0.0 to 99.9
0.1
ECONO_I
EC.D
Economizer PID --- kD
0.0 to 99.9
1
ECONO_D
EC.DT
Economizer PID --- rate
10.0 to 180.0
sec
15
ECONO_DT
E.DBD
Economizer PID
Deadband
0 to 25
%
3
ECONBAND
CP.P
Capacity PID --- kP
0 to 99.9
1.5
VCAP_P
CP.I
Capacity PID --- kI
0 to 99.9
0.1
VCAP_I
CP.D
Capacity PID --- kD
0 to 99.9
1
VCAP_D
CP.DT
Capacity PID --- rate
1 to 30
secs
5
VCAP_DT
LK.P
Linkage Staging PID --- kP
0.0 to 99.9
10
LINK_P
LK.I
Linkage Staging PID --- kI
0.0 to 99.9
5
LINK_I
LK.D
Linkage Staging PID --- kD
0.0 to 99.9
5
LINK_D
LK.DT
Linkage Staging PID ---
rate
10.0 to 180.0
secs
30
LINK_DT
