58
TO MAIN
BASE BOARD
RED
BLK
RED
BLK
RED BLK
SENSOR 1 SENSOR 2 SENSOR 3
RED
BLK
SENSOR 6 SENSOR 5
RED
BLK
SENSOR 4
RED BLK
RED
BLK
RED
BLK
SENSOR 8 SENSOR 7 SENSOR 9
1
RED
BLK
TB1-T55
SENSOR 1 SENSOR 2 SENSOR 3 SENSOR 4
RED
BLK
RED
BLK
RED
BLK
RED
BLK
TO MAIN
BASE BOARD
RED
BLK
TB1-T55
1
2
2
SPACE TEMPERATURE AVERAGING --4 T-55 SENSOR APPLICATION
SPACE TEMPERATURE AVERAGING --9 T-55 SENSOR APPLICATION
LEGEND
TB -- Terminal Block
______ -- Factory Wiring
_ _ _ _ -- Field Wiring
C07032
Fig. 26 -- Space Temperature Sensor Averaging
T-55 SENSOR 1 T-55 SENSOR 2 T-55 SENSOR 3 T-56 SENSOR 4
RED
BLK
RED
BLK
RED
BLK
RED
BLK
TO MAIN
BASE
BOARD
RED
BLK
TB1-T55
1
2
TO MAIN
BASE
BOARD
3
TB1-T55
WHT
C07033
Fig. 27 -- Space Temperature Sensor Averaging with 3 T--55 Sensors and One T--56 Sensor
