APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)

Table 34 — MODE - CONFIGURATION (cont)

ITEM

EXPANSION

RANGE

UNITS

DEFAULT

CCN

TABLE/SUB---TABLE

CCN POINT

PAGE

NO.

HEAT

Heating Configuration

HEAT_CFG

HT.TY

Type of Heat Installed

0=No Heat

1=Gas

2=Electric

0 (50 series with no

electric heat)

1 (48 series)

2 (50 series with

electric heat)

HEATTYPE

20

N.HTR

Number of Heat Stages

1 to 2

1 (50 series <15kW)

2 (48 series, 50

series >=15kW)

NUM_HEAT

22

MRT.H

Heat Minimum On Time

60 to 999

sec

120

HMIN_ON

22

MOT.H

Heat Minimum Off Time

60 to 999

sec

120

HMIN_OFF

22

H.DEC

Heat Stage Decrease

Time

120 to 999

sec

300

HSTAGDEC

22

H.INC

Heat Stage Increase Time

120 to 999

sec

450

HSTAGINC

21

FOD.E

Fan--- off Delay, Elect Heat

10 to 600

sec

30

ELEC_FOD

22

FOD.G

Fan--- off Delay, Gas Heat

45 to 600

sec

45

GAS_FOD

20

HT.LO

Heating Lockout Temp

40 to 125F

dF

75

OATLHEAT

20

SAT

SUPPLY AIR

TEMPERATURE

SAT.H

SAT Heat Mode Sensing

Enable/Disable

Disable

SAT_HEAT

21

SAM.L

Maximum SAT Lower

Level

85 to 200

dF

140

SATMAX_L

21

SAM.U

Maximum SAT Upper

Level

85 to 200

dF

160

SATMAX_H

21

SPT

SPACE TEMPERATURE

HT.PD

SPT Heat Demand (+)

Level

0.5 to 5

^F

1

HDEM_POS

21

HT.ND

SPT Heat Demand (--- )

Level

--- 5 to --- 0.5

^F

--- 1

HDEM_NEG

21

H.LAG

Heat Thermal Lag Factor

0 to 5

min

1

HEAT_LAG

21

ECON

Economizer Configuration

ECON_CFG

EC.EN

Economizer Installed

Yes/No

No: no FIOP

Yes: FIOP

ECONO

8

E.CTL

Economizer Control Type

1=Dig/Position

2=Dig/Command

3=Analog Ctrl

1

ECON_CTL

10

MP.25

Econ Min at 25%

Fanspeed

0 to 100

%

0

MINP_25

19

MP.50

Econ Min at 50%

Fanspeed

0 to 100

%

0

MINP_50

19

MP.75

Econ Min at 75%

Fanspeed

0 to 100

%

0

MINP_75

19

MP.MX

Econ Min at Max

Fanspeed

0 to 100

%

30

MINP_MAX

19

EC.MX

Econo Cool Max Position

0 to 100

%

100

ECONOMAX

M.ANG

Min Actuator Ctrl Angle

75 to 90

88

MINANGLE

27

EH.LO

Econo Cool Hi Temp Limit

40 to 100F

dF

65

OATLECLH

15

EL.LO

Econo Cool Lo Temp Limit

--- 30 to 50F

dF

0

OATLECLL

15

DF.DB

Diff Dry Bulb Control

Disable/Enable

Enable

DIFFBULB

UEFC

Unoccupied Free Cooling

0=Disabled

1=Unoccupied

2=Preoccupancy

2

UEFC_CFG

15

FC.TM

Free Cool PreOcc Time

1 to 9999

min

120

UEFCTIME

16

FC.LO

Free Cool Low Temp Limit

--- 30 to 70F

dF

50

OATLUEFC

16

PE.EN

Power Exhaust Installed

Yes/No

No: no FIOP

Yes: FIOP

PE_ENABL

16

PE1.C

Power Exhaust Stage1

CFM

100 to 15000

cfm

600

PE1_CFM

16

PE2.C

Power Exhaust Stage2

CFM

100 to 15000

cfm

0

PE2_CFM

16

IDF.C

Indoor Fan Max Speed

CFM

500 to 15000

cfm

1600 (05)

2000 (06)

IDF_CFM

16

EN.SW

Enthalpy Switch

0=No Switch

1=Normal Open

2=Normal Closed

0: no FIOP

1: FIOP

ENTHLCFG

59
