APPENDIX A - LOCAL DISPLAY AND CCN TABLES (CONT)
Table 34 — MODE - CONFIGURATION (cont)
ITEM EXPANSION RANGE UNITS DEFAULT
CCN
TABLE/SUB---TABLE
CCN POINT
PAGE
NO.
AIR.Q Air Quality Config. IAQ_CFG
IA.CF IAQ Analog Input Config 0=No IAQ
1=DCV
2=Override IAQ
3=Ctrl Min Pos
0: no FIOP
1: FIOP
IAQANCFG 59
IA.FN IAQ Analog Fan Config 0=Never
1=Occupied
2=Always
0 IAQANFAN 14
II.CF IAQ Switch Input Config 0=No IAQ
1=DCV N/O
2=DCV N/C
3=Override N/O
4=Override N/C
0 IAQINCFG 17
II.FN IAQ Switch Fan Config 0=Never
1=Occupied
2=Always
0 IAQINFAN 17
AQ.MN Econo Min IAQ Position 0 to 100 % 10 IAQMINP 17
OVR.P IAQ Override Position 0 to 100 % 100 IAQOVPOS 17
OA.CF OAQ Analog Input Config 0=No OAQ
1=DCV
2=Lockout OAQ
0 OAQANCFG 17
OAQ.L OAQ Lockout Limit 0 to 5000 600 OAQLOCK 17
AQD.L AQ Differential Low 0 to 5000 100 DAQ_LOW 19
AQD.H AQ Differential High 0 to 5000 700 DAQ_HIGH 19
DF.ON Fan On AQ Differential 0 to 5000 600 DAQFNON 17
DF.OF Fan Off AQ Differential 0 to 5000 200 DAQFNOFF 17
I.4M IAQ Sensor Value at 4mA 0 to 5000 0 IAQ_4MA 16
I.20M IAQ Sensor Value at 20mA 0 to 5000 2000 IAQ_20MA 16
O.4M OAQ Sensor Value at 4mA 0 to 5000 0 OAQ_4MA 17
O.20M OAQ Sensor Value at
20mA
0 to 5000 2000 OAQ_20MA 17
H.4M RH Sensor Value at 4mA 0 to 50 % 0 RH_4MA
H.20M RH Sensor Value at 20mA 60 to 100 % 100 RH_20MA
ALM.O Alarm Relay Config. ALM_CFG
A.SPC SPT/SPRH Sensor Failure Yes/No Yes SPACE_AL
A.SRT SAT/RAT Sensor Failure Yes/No Yes SATRATAL
A.OAT OAT Thermistor Failure Yes/No Yes OAT_AL
A.CS Current Sensor Failure Yes/No No CS_AL
A.CMP Compressor Failure Yes/No Yes COMP_AL
A.CKT Refrig Circuit Failure Yes/No Yes CKT_AL
A.SSP SSP Transducer Failure Yes/No Yes SSP_AL
A.SCT SCT Thermistor Failure Yes/No Yes SCT_AL
A.FAN Indoor Fan Failure Yes/No Yes FAN_AL
A.FIL Dirty Filter Yes/No Yes FILT_AL
A.ECO Economizer Failure Yes/No Yes ECON_AL
PID PID Configurations PID_CFG
EC.P Economizer PID --- kP 0.0 to 99.9 2.5 ECONO_P
EC.I Economizer PID --- kI 0.0 to 99.9 0.1 ECONO_I
EC.D Economizer PID --- kD 0.0 to 99.9 1 ECONO_D
EC.DT Economizer PID --- rate 10.0 to 180.0 sec 15 ECONO_DT
E.DBD Economizer PID
Deadband
0 to 25 % 3 ECONBAND
CP.P Capacity PID --- kP 0 to 99.9 1.5 VCAP_P
CP.I Capacity PID --- kI 0 to 99.9 0.1 VCAP_I
CP.D Capacity PID --- kD 0 to 99.9 1 VCAP_D
CP.DT Capacity PID --- rate 1 to 30 secs 5 VCAP_DT
LK.P Linkage Staging PID --- kP 0.0 to 99.9 10 LINK_P
LK.I Linkage Staging PID --- kI 0.0 to 99.9 5 LINK_I
LK.D Linkage Staging PID --- kD 0.0 to 99.9 5 LINK_D
LK.DT Linkage Staging PID ---
rate
10.0 to 180.0 secs 30 LINK_DT
