Page 58 MSI-9850 RF Remote Indicator • User Guide
MSI-9850
HANDHELD RF REMOTE INDICATOR for
C
ELL
S
CALE
®
Multi-Channel Preset Displays
Multi-channel presets use the scan list position to assign channels to specific locations. After selecting the preset
multi-channel display, the user can reassign any channel in the scan list to any screen location.
The Multi-Channel Preset Displays are described by line numbers 1-8 corresponding to the small font layout. The
numbers in the sample screens and descriptions correspond to the scan list position index (SLI).
The 9850 reads the scan list out of the master CellScale. If a multi-channel preset is selected that allows more
channels than the CellScale has in its scan list, the preset will show just the available channels. If space allows
the Date and Time will appear on the bottom line (Line 8).
3 Ch -1 lg, 2 sm – This display is primarily intended for summing where scan list positions
1 and 2 are scale channels, and position 3 is a math channel that sums the two scale weights.
However, any type of channel list can be used with this display and the list order can be
changed after this preset is selected. Lines 1-4: SLI 3 large current weight display (-Weight-).
Line 5: SLI 1 Current Weight and Network address. Line 6: SLI 1 Channel Name (if pro-
grammed in the CellScale). Line 7: SLI 2 Current Weight. Line 8: SLI 2 Channel Name.
4 Ch - 4 sm + data – This display shows four channels along with each channels Channel
Name. The Channel name must be programmed into the CellScale for it to appear. If less than
four channels exist in the scan list, the bottom channel will be replaced with the date/time/enter
number line. Line 1: SLI 1 Current Weight preceded by the scan list number. Line 2: SLI 1
Channel Name. SLI 2-4 follow the same format.
2 Ch -2 med+ data – This display shows two channels along with each channels 8 character ID
Name and 20 character ID String 1. Lines 1-2: SLI 1 Current Weight preceded by the scan list
number. Line 3: SLI 1 Channel Number (e.g. 1-1), SLI 1 ID Name, and the Network Address.
Line 4: SLI 1 ID String 1. Line 5-6: SLI 2 Current Weight preceded by the scan list number.
Line 7: SLI 2 Channel Number (e.g. 2-1), SLI 2 ID Name. Line 8: SLI 2 ID String 1.
4 Ch - 4 med – Displays 4 channels in the 9850 medium size font. The weight data is preceded
by the scan list position index number (1-32). If less than four channels exist in the scan list,
the bottom channel will be replaced with the date/time/enter number line. Lines 1-2: SLI 1
Current Weight preceded by the scan list number. Lines 3-4: SLI 2 Current Weight preceded by
the scan list number. Lines 5-6: SLI 3 Current Weight preceded by the scan list number. Lines
7-8: SLI 1 Current Weight preceded by the scan list number.
8 Ch - 8 small – Maximum channel count display of up to eight channels. Each channel is pre-
ceded by the scan list position index number (1-32). If less than eight channels exist in the scan
list, the bottom channel will be replaced with the date/time/enter number line.
3’s-Wei
g
1’s-Weight---- ADR
1’s-Ch-Name---------
2’s-Weight----
2’s-Ch-Name---------
1S 1’s-Weight----
1Ch 1’s-IdNm ADR
1’s-1-ID-String-----
2S 2’s-Weight----
2Ch 2’s-IdNm
2’s-1-ID-String-----
1SL 1’s-Weight----
1’s-Ch-Name---------
2SL 2’s-Weight----
2’s-Ch-Name---------
3SL 3’s-Weight----
3’s-Ch-Name---------
4SL 4’s-Weight----
4’s-Ch-Name---------
1S 1’s-Weight----
2S 2’s-Weight----
3S 3’s-Weight----
4S 4’s-Weight----
1SL 1’s-Weight----
2SL 2’s-Weight----
3SL 3’s-Weight----
4SL 4’s-Weight----
5SL 5’s-Weight----
6SL 6’s-Weight----
7SL 7’s-Weight----
8SL 8’s-Weight----
