MSI CellScale
®
System • 9850 User Guide Page 39
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
Print Aux to Comm 1
...Sends the Aux 1 string directly to Comm Port 1.
Print Aux to Comm 2
...Sends the Aux 2 string directly to Comm Port 2.
Print Aux to Comm’s
...Sends both Aux strings to their respective Comm Ports.
Send to CSRF Host 1
...Tells the Master CellScale to output its Host 1 output string (CellScale local Comm
Port)
Send to CSRF Host 3
...Tells the Master CellScale to output it’s Host3 print string.
Send to CSRF Host 4
...Tells the Master CellScale to output it’s Host1 print string.
Send to CSRF Host 5
...Tells the Master CellScale to output it’s Host5 print string.
Send to CSRF Hosts
....Tells the Master CellScale to output all connected print strings.
Print 1 Send Host 1
......Outputs Comm 1 print string to the Comm 1 connector, and tells the CellScale to output
it’s Host1 print string.
Print 2 Send Host 1
......Outputs Comm 2 print string to the Comm 2 connector, and tells the CellScale to output
it’s Host1 print string.
Print & Send Host 1
.....Outputs both 9850 Comm Port print strings out their respective connectors, and tells
the CellScale to output it’s Host1 print string.
Print 1 Send Host 3
......Outputs Comm 1 print string to the Comm 1 connector, and tells the CellScale to output
it’s Host3 print string.
Print 2 Send Host 3
......Outputs Comm 2 print string to the Comm 2 connector, and tells the CellScale to output
it’s Host3 print string.
Print & Send Host 3
.....Outputs both 9850 Comm Port print strings out their respective connectors, and tells
the CellScale to output it’s Host3 print string.
Print 1 Send Host 4
......Outputs Comm 1 print string to the Comm 1 connector, and tells the CellScale to output
it’s Host4 print string.
Print 2 Send Host 4
......Outputs Comm 2 print string to the Comm 2 connector, and tells the CellScale to output
it’s Host4 print string.
Print & Send Host 4
.....Outputs both 9850 Comm Port print strings out their respective connectors, and tells
the CellScale to output it’s Host4 print string.
Print 1 Send Host 5
......Outputs Comm 1 print string to the Comm 1 connector, and tells the CellScale to output
it’s Host5 print string.
Print 2 Send Host 5
......Outputs Comm 2 print string to the Comm 2 connector, and tells the CellScale to output
it’s Host5 print string.
Print & Send Host 5
.....Outputs both 9850 Comm Port print strings out their respective connectors, and tells
the CellScale to output it’s Host5 print string.
Send All & Print 1
.........Tells the CellScale to output all of its print strings and the 9850 to output the Comm
Port 1 String.
Send All & Print 2
.........Tells the CellScale to output all of its print strings and the 9850 to output the Comm
Port 2 String.
Send All & Print All
.......Tells the CellScale to output all of its print strings and the 9850 to output both Comm
Port Strings.
Start/Stop Comm 1
.......If the Comm 1 print string is set to an automatic or continuous output mode, this func-
tion key will act as a start/stop print key.
Start/Stop Comm 2
.......If the Comm 2 print string is set to an automatic or continuous output mode, this func-
tion key will act as a start/stop print key.
5 – Edit Strings
Edit CS String
..............Allows direct entry into the Master CellScale Comm 1 print string edit screen. This
print string outputs on the CellScale Comm Port 1 connector.
Edit Print String
1
.........Allows direct entry into the 9850 Comm 1 print string edit screen. This is the print
string used for Data Logging as well as printing out the 9850 Comm Port 1.
Edit Print String
2
.........Allows direct entry into the 9850 Comm 2 print string edit screen. This is the print
string used for printing out the 9850 Comm Port 2.
Edit Aux String
1
...........Allows direct entry into the 9850 Comm 1 aux print string edit screen.
Edit Aux String
2
...........Allows direct entry into the 9850 Comm 2 aux print string edit screen.
Edit CSRF Host 3
..........Allows the 9850 to edit the CellScales RF Host 3 string which is used to communicate
with remote modems.
Edit CSRF Host 4
..........Allows the 9850 to edit the CellScales RF Host 4 string which is used to communicate
with remote modems.
Edit CSRF Host 5
..........Allows the 9850 to edit the CellScales RF Host 5 string which is used to communicate
with remote modems.
