MSI CellScale
®
System • 9850 User Guide Page 37
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
DEFAULT FUNCTION KEYS
Next Product ID
.............F1. When pressed, switches to the next available ID Code defined for the current
channel. When preceded by a number, will switch directly to the numbered ID. This
always works, even if F6 is programmed for another function.
DATA 1
.............................F2. Get Data for field Bar Code 1.
DATA 2
.............................F3. Get Data for field Bar Code 2.
DATA 3
.............................F4. Get Data for field Bar Code 3.
RF Address
....................F5. When pressed, switches to the next available Network Address. When preceded
by a number (0-63), will switch directly to the numbered network. This always works,
even if F5 is programmed for another function.
Xmit All
............................F6. Causes all programmed strings to Output, both local Comm Ports 1 and 2, and the
Host Comm Ports 1, 3, 4, and 5.
Next Channel
.................F7. When pressed, changes to the next channel in the Scan Index. Switch between
selected scale channels. If preceded by a number (1-32), the display will show the
chosen channel position from the Channel scan list. This always works, even if F7 is
programmed for another function.
Add to Total
....................F8. Add the current weight to the total, or Auto Total On/Off while unit is in Auto-Total
modes.
View Total LED
..............F9. Switches the LCD to display current ID Total values and shows the Total Weight
on the LED Display for 3 seconds.
Display
............................F10. Switches LCD screen between single channel and multi-channel displays.
DEFAULT ENTER-FUNCTION KEYS
(shifted functions)
New ID
.............................ENTER-F1. Brings up text entry screen for creation of a new ID.
User String 1
..................ENTER-F2. Text entry screen for ID User String 1.
User String 2
..................ENTER-F3. Text entry screen for ID User String 2.
DATA 4
.............................ENTER-F4. Get Data for field Bar Code 4.
Back RF Address
..........ENTER-F5. When pressed, steps back one position in the available Network Address
list.
Send to CS
.....................ENTER-F6. Tells the CellScale master to output its virtual Comm Port 3.
Back Channel
................ENTER-F7. When pressed, steps back one channel in the Scan Index.
Clear Last Total
.............ENTER-F8. Deletes the previously totaled weight.
View Grand Total
..........ENTER-F9. Switches LCD to Grand Total (of all IDs) display screen.
Test Displays
.................ENTER-F10. Starts Display Test.
DEFAULT EXTERNAL (P2) SWITCHES
Power
...............................X1. Turns the Power On and Off.
Zero
..................................X2. Performs Scale Zero function (current focus channel).
Add to Total
....................X3. Adds the current weight to the Total.
Disabled
..........................X4. No default function assigned. This line is often used to drive an external power
LED.
DEFAULT RF REMOTE KEYS
View Total (∑)
.................R1. Switches LCD screen to display current ID Total values. Shows Total on Large
LED for 3 seconds.
Total
.................................R2. Add to Total. Also functions as Total On/ Total Off in Auto-Total modes.
Net/Gross
........................R3. Toggles focus channel between Net and Gross displays.
Tare
...................................R4. Tares current weight and displays Net weight.
F2
......................................R5. Send. ????
F1
......................................R6. Shift RF ????
Zero
..................................R7. Zeros the scale (current focus channel).
Power
...............................R8. 9850 Power On/Off. This is the only key function not changeable.
DEFAULT RF REMOTE KEYS
View Total (∑)
.................R1. Switches LCD screen to display current ID Total values. Shows Total on Large
LED for 3 seconds.
