MSI CellScale
®
System • 9850 User Guide Page 55
MEASUREMENT SYSTEMS INTERNATIONAL
Firmware Version 5-XX for 2450 Modems
KEYBOARD LOCK
Keyboard lock is provided to prevent casual or accidental pressing of the keys from changing any modes. This
function works only from weight display modes.
1) Press
POWER
followed immediately by
ESC
(
SETUP
). The startup screen will appear.
2) Press the
CLR
(
ZERO
) key. A password text entry screen will appear.
3) Using the keypad, input the number 7415369. Press
ENTER
.
4) The “ARE YOU SURE” display appears. Press
ENTER
.
Everything is reverted to defaults. Now you must setup the 9850 again.
RESET ALL: The following procedure will cause you to lose all setups and will return
the 9850 to it’s default settings. Use this procedure only as the last resort of having lost
your password.
To Lock the Keyboard
Press
[1] [2] [3]
ALPHA
. The screen will read “KEYBOARD LOCKED” briefly.
While in Keylock mode, pressing any key will show the screen “KEYLOCK PUSH 123””
To Unlock the Keyboard
Press
[1] [2] [3]
. The screen will read “KEYBOARD UNLOCKED” briefly.
Now all keys should function normally.
SCALE DISPLAY SETUP
1 Single Scale Mode
2 Multi Scale Mode
3 Backlight
2min
4 Backlight Level
3
5 Contrast
10
BACKLIGHT
1 Off (max batt-life)
2 On for 15 seconds
3 On for 30 seconds
4 On for 1 minute
5 On for 2 minutes
6 On (min batt-life)
7 Light on Motion OFF
7 Light on Motion OFF
7 Light on Motion ON
SCALE DISPLAY SETUP
Shortcut
BACKLIGHT
BACKLIGHT BRIGHTNESS
ESC exits no change
ENTER edits value
0-9 replaces value
2
min = Ø, max = 3
^ incs, v decs value
BACKLIGHT BRIGHTNESS
BACKLIGHT BRIGHTNESS
ESC exits no change
ENTER edits value
0-9 replaces value
1Ø
min = Ø, max = 3
^ incs, v decs value
DISPLAY CONTRAST
ESC
!
SETUP
DISPLAY
EXIT
7
STU
4
JKL
5
MNO
LC DISPLAY BACKLIGHT & CONTRAST
The 9850 features a white LED Backlit Liquid Crystal Display. The LED Backlight is one of the highest power
drain devices in the 9850. The Backlight can be set to turn itself off automatically after a user sepcified time.
Once off, the Backlight will turn back on by pushing any key (except
POWER
). The first key press, no matter
which key it is, will be ignored, except for turning the Backlight on. Then key function is restored. The Backlight
can also be set to turn back on when the active channel scale changes its reading (goes in motion). There are 3
levels of brightness with a setting of 0 being another way to turn it off. AC or DC supply powered 9850’s can
and should choose to leave the backlight on at full (3) brightness. In battery powered units, battery life can be
extended through the use of the power down modes and reduced brightness settings.
1) Press
SETUP
,
DISPLAY
,
[3]
. The BACKLIGHT menu
appears. Select the desired on time from 2-6. Off (1) is
usually not desired as this is a transmissive display and has
poor contrast without a backlight. On AC Powered units,
choice 6, always on, is the preferred choice.
2) Press
[7]
to change the Light on Motion setting from OFF
to ON. When ON, the backlight will turn back on whenever
the current scale channel changes its reading. However set-
ting Light on Motion On may prevent the backlight from
ever turning off, thus decreasing battery life in battery
powered units.
3) Press
ESC
to backup to the SCALE DISPLAY SETUP
menu. Press
[4]
to change the backlight brightness level.
A setting of 0 turns off the backlight. 4 is the brightest. Set
the brightness level as low as is useful in your environment.
Press
ENTER
to set your brightness choice.
Setting the LCD Backlight
