Table of Contents v
Chapter 6 Configuration and Activation 6-1
Configuring the Monitor Location ................................. 6-3
Launching the Profile Software ............................... 6-3
Creating a Monitor Location ................................... 6-5
Creating an Installation Table ................................. 6-7
Selecting and Editing Devices ............................... 6-11
Setting the Communication Parameters ........................ 6-21
Activating the Monitor ................................................. 6-25
Running Device Diagnostics ........................................ 6-28
Collecting Data from the Monitor ................................ 6-37
Upgrading the Monitor Firmware ................................. 6-46
Viewing Diagnostic and Data Logs .............................. 6-49
Chapter 7 Monitor Installation 7-1
Mounting the Monitor to the Manhole Wall................... 7-4
Mounting the Monitor to the Manhole Rim.................... 7-7
Chapter 8 Analog Input/Output Installation
and Configuration 8-1
Analog Inputs ................................................................. 8-3
Gathering Tools and Equipment.............................. 8-3
Connecting Analog Inputs ....................................... 8-4
Verifying the Analog Input Values ......................... 8-8
Analog Outputs .............................................................. 8-9
Loop Power ........................................................... 8-10
Signal Connection ................................................. 8-10
Typical Analog Output Installation ....................... 8-13
Chapter 9 Modbus 9-1
Configuring the FlowShark Monitor to Operate in
Real-Time................................................................ 9-3
Defining the Modbus Register Values ............................ 9-5
Modbus Data Type .................................................. 9-6
Connecting the FlowShark to Modbus ........................... 9-7
RS232 Port Settings ................................................ 9-7
Verifying Modbus Output Values .................................. 9-8
