Specifications A-7
Operating Speed 19.2K baud with fallback to 9600 and 1200 as
required for reliable communication
Protocol Accuyapp over analog modem connection
Service Type Regular 2-wire voice grade POTS line
Analog 4-20mA I/O Board (5000-0517)
Inputs/Outputs
• Accubus High-Speed I/O (to other internal
PCBs)
• Power from Voltage Regulator Board
Analog Inputs
Number - Two 4-20mA Inputs
Load Resistance – 100 ohms
Accuracy – 0.5% FS
Maximum voltage relative to ground – 240Vrms
Analog Outputs
Number - Two fully isolated 4-20mA Outputs
(optional 0-5V and 0-20mA configuration)
Isolation - 1500Vrms common mode relative to
ground
Maximum Load – 1000 ohms (using 24VDC
external loop supply)
Linearity and Stability - +/- 0.01mA
Resolution – 0.005mA
I/O- Loop Power
Connection
I/O and external output loop power supplied via
ADS cable p/n 5000-0698
Voltage Regulator Board (5000-0518)
Inputs 7.5 to 12 volts (from internal or external source)
Outputs Regulated 6v and 12v to DSP, Comm, Analog,
and 4-20mA Analog I/O PCBs
