A-8 ADS FlowShark Manual
ADS Power Supply (5000-0727)
Size 5.1 inches long x 5.1 inches wide x 5.1 inches
high
Material Polycarbonate
Rating NEMA 4X
Mounting Panel mounting via four 0.175” holes
Input Voltage 100-240VAC, 50/60Hz
Output Voltage 12V DC, 1.2A
Connection AC: Supplied 6’ Line Cord (US) or hardwire to AC
input terminals
DC: Hardwire to DC output terminals
Sensors
The following includes specifications for the ultrasonic depth
sensor, Doppler velocity sensor, and pressure depth sensor.
Ultrasonic Depth Sensor (103262A-30)
Housing Marine-grade aluminum/epoxy
Dimensions 7.13 inches long x 4.20 inches wide x 0.86 inches
high
Accuracy 0.125 inches
Deadband Less than 1 inch
Frequency 40 kHz
Range 0.5 inches to 12.5 feet
