Configuration and Activation 6-49
Viewing Diagnostic and Data Logs
Profile generates detailed logs for many activities performed
through Diagnostics, such as monitor activation, data collection,
and firmware downloading. These logs are available immediately
following the activity and for future access to historical information.
1. Select the monitor location for which you want to view an
activity log from the Profile main screen, and then click on the
Diagnostics toolbar button.
Diagnostics toolbar button
The Monitor Diagnostics dialog displays.
Monitor Diagnostics dialog
2. Select the monitoring point for which you want to view a log
from the Monitoring Point drop-down list.
