A-10 ADS FlowShark Manual
Doppler Velocity Sensor (103260A-35)
Enclosure Solid machined PVC/epoxy
Dimensions 2.35 inches long x 1.13 inches wide x 0.49 inches
high
Accuracy ± 0.2 feet per second or 4% of actual peak velocity
(whichever is greater) in flow velocities from -20 .0
to 20.0 fps
Resolution 0.04 feet per second
Cable Standard size: 35 feet long x 0.25 inches diameter
OD polyurethane jacket
Extension cables available up to 300 feet
Lightning Protection Module (103313)
The following table contains the specifications for the lightning
protection module at the service location.
Housing Gray PVC
Dimensions 4.13 inches high x 3.25 inches wide x 1.88 inches
deep
Polyswitch 600-volt 150-milliamps over-current protector
Varistor 240-volt over-voltage protector
Sidactor 280-volt over-voltage protector
Ground Wire 12 AWG black stranded
Service Wire 22 AWG 4-conductor gray unshielded
