9-2 DeviceNet Communications Module
9.1.1 DRIVE Status Indicator
Table 9.1 – DRIVE Status Indicator: State Definitions
Status Cause Corrective Action
Off The module is not
powered or is not
connected properly to the
drive. • Securely connect the module to the
drive using the ribbon cable.
• Apply power to the drive.
Flashing
Red The module is not
receiving communication
from the drive, connected
drive is faulted, or a drive
is missing in Multi-Drive
mode. • Clear any drive faults.
• Verify that cables are securely
connected.
• Cycle power to the drive.
Solid
Red The drive has refused an
I/O connection from the
module.
Another MDI peripheral is
using the same MDI port
as the module.
Important: Cycle power to the
product after making the following
correction:
Verify that all MDI cables are securely
connected and not damaged. Replace
cables if necessary.
Flashing
Green The module is establishing
an I/O connection to the
drive or (DSI I/O Config) is
configured for all I/O
disabled. • No Action. This status indicator will
turn solid green or red.
• Verify Parameter 15, (DSI I/O
Config) settings.
• Normal behavior if no MDI (DSI) I/O
is enabled.
Solid
Green The module is properly
connected and is
communicating with the
drive. No Action.
Orange Daisy-chained drives in
Multi-Drive mode are not
all MD60 or MD65 drives. Use MD60 and MD65 drives for the
daisy-chained drives.
