B-8 DeviceNet Communications Module
Sets the configuration of the drives that are active in the Multi-Drive
mode. Identifies the connections that would be attempted on a reset
or power cycle.
Displays the drives that are active in the Multi-Drive mode.
Sets the corresponding node addresses of the daisy-chained drives
when the module Mode Jumper (J2) is set for Multi-Drive operation.
Important: The setting for these parameters must match the setting
of parameter A104 (Comm Node Addr) in the respective
drives. Each setting must also be unique (no duplicate
node address).
15 DSI I/O Cfg
Range: 0 = Drive 0
1 = Drives 0-1
2 = Drives 0-2
3 = Drives 0-3
4 = Drives 0-4
Default: 0001
Type: Read/Write
Reset Required: Yes
16 DSI I/O Act
Range: 0 = Drive 0
1 = Drives 0-1
2 = Drives 0-2
3 = Drives 0-3
4 = Drives 0-4
Default: 0001
Type: Read Only
Reset Required: N/A
17
18
19
20
21 Drv 0 Addr
Drv 1 Addr
Drv 2 Addr
Drv 3 Addr
Drv 4 Addr
Range: 1 to 247
Default: 17 = 1
18 = 2
19 = 3
20 = 4
21 = 5
Type: Read/Write
Reset Required: Yes
