Installing the DeviceNet Module 3-1
C
HAPTER
3
Installing the
DeviceNet Module
Chapter 3 provides instructions for installing the DeviceNet module
in an MD65 drive.
3.1 Preparing for an Installation
Before installing the DeviceNet module:
• Read the DeviceNet Product Overview Manual , Publication
DN-2.5, and the DeviceNet Cable System Planning and
Installation Manual , Publication DN-6.7.2. These manuals will
provide information on selecting cables, setting up a network, and
network basics.
• Verify that you have all required equipment. Refer to chapter 2,
Getting Started.
3.2 Commissioning the Module
To commission the module, you must set a unique node address
and the data rate that is used by the network. (Refer to the Glossary
for details about data rates and node addresses.)
Important: New settings are recognized only when power is applied
to the module. If you change a setting, cycle power.
Step 1. Set the node address and data rate switches as shown in
figure 3.1.
Step 2. Set the module mode jumper for Single- or Multi-Drive
operation. See figure 3.1 and table 3.3.
!
ATTENTION: The DeviceNet module contains
ESD- (Electrostatic Discharge) sensitive parts that
can be damaged if you do not follow ESD control
procedures. Static control precautions are required
when handling the module. Failure to observe these
precautions could result in damage to equipment.
