2-2 DeviceNet Communications Module
2.2 Required Equipment
Table 2.2 lists the equipment shipped with the DeviceNet module.
When you unpack the module, verify that the package includes all of
these items.
Table 2.3 lists user-supplied equipment also required to install and
configure the DeviceNet module.
Table 2.2 – Equipment Shipped with the DeviceNet Module
Item Description
DeviceNet module
15.24 cm (6 in) Internal Interface cable
Five-pin linear DeviceNet plug (connected to the DeviceNet
connector on the module)
Grounding wrist strap
DeviceNet Module User Manual (D2-3520)
Table 2.3 – Required User-Supplied Equipment
Item Description
A small flathead screwdriver
DeviceNet cable
• Thin cable with an outside diameter of 6.9 mm (0.27 in.) is
recommended
Configuration tool, such as:
• LCD OIM
• VS Utilities
• RSNetWorx for DeviceNet
• Serial Converter
Computer with a DeviceNet communications module installed
(such as 1784-PCD, 1784-PCID, 1784-PCIDS, or 177-KFD)
Controller configuration software (examples: RSLogix5,
RSLogix500, or RSLogix 5000)
DeviceNet Cover Kit (replaces standard cover supplied with
MD65 drive when the DeviceNet module is installed).
• B-Frame: Model Number 6MD-COMMCVRB
• C-Frame: Model Number 6MD-COMMCVRC
