Configuring the DeviceNet Module 4-13
4.10 Viewing the Module Configuration
The parameters in table 4.8 provide information about how the
module is configured. You can view these parameters at any time.
Table 4.8 – Module Configuration Parameters
Number Name Description
01 Mode The mode in which the module is set
(0 = Single drive operation, or 1 = Multi-Drive
operation).
03 DN Addr
Actual The node address used by the module. This
will be one of the following values:
• The address set by the module DIP
switches 1 through 6.
• The value of DN Addr Config (2) if the
switches have been disabled.
• An old address of the switches or
parameter if they have been changed and
the module has not been reset.
05 DN Rate
Actual The data rate used by the module. This will
be one of the following values:
• The data rate set by the module DIP
switches 7 and 8.
• The value of DN Rate Config (4) if the
switches have been disabled.
• An old data rate of the switches or
parameter if they have been changed and
the module has not been reset.
09 DN
Active
Config The source from which the module node
address and data rate are taken. This will be
either switches or parameters in EEPROM. It
is determined by the settings of the module
DIP switches 1 through 8.
16 DSI I/O
Actual Indicating the drives that make up the node:
Values:
0 = Drive 0
1 = Drives 0-1
2 = Drives 0-2
3 = Drives 0-3
4 = Drives 0-4
