Ppendix, Technical specifications – Rockwell Automation DeviceNet Communications Module User Manual
Page 105
Technical Specifications
A-1
A
PPENDIX
A
Technical
Specifications
Communications
Electrical
Mechanical
Environmental
Regulatory Compliance
Network
Protocol
Data Rates
Drive
Protocol
DeviceNet
125K, 250K, 500K, Autobaud
MDI
Consumption
Drive
Network
150 mA at +5 V supplied through the drive
60 mA at +24 V supplied through DeviceNet
Use the 60 mA value to size the network
current draw from the power supply.
Dimensions
Height
Length
Width
19 mm (0.75 in)
86 mm (3.33 in)
78.5 mm (3.09 in)
Weight
85 g (3 oz)
Temperature
Operating
Storage
-10 to +50
°
C (14 to 149
°
F)
-40 to +85
°
C (-40 to 185
°
F)
Relative Humidity
5 to 95% non-condensing
UL
UL508C
cUL
CAN / CSA C22.2 No. 14-M91
CE
EM50178 and EN61800-3
