D-2 DeviceNet Communications Module
* A 0 = Not Stop condition (logic 0) must first be present before a 1 = Start condition will start the drive.
x x x Reference Select 000 = No Command
001 = Freq Source = Select
010 = Freq Source = Int. Freq
011 = Freq Source = Comm
100 = Preset Freq 1
101 = Preset Freq 2
110 = Preset Freq 3
111 = Preset Freq 4
x MOP Decrement 0 = Not Decrement
1 = Decrement
Logic Bits
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Command Description
