Page 81

Publication 8720MC-IN002A-EN-P — December 2002
SCANport Command Interface
4-7
Rotation Direction - The rotation direction bit is used to identify the
direction of motor rotation.
Manual Reference Selected - Whenever the digital or SCANport
interfaces select the manual reference the drive acknowledges this
state by setting the manual reference selected bit 15, SCANport Output
Status Word.
The table below describes the fixed assignments for the eight 16 bit
input data words and the eight 16 bit output data words.
SCANport Data Interface
In addition to the SCANport Logic Command word, the SCANport
Logic Status word, the SCANport Command Reference and the
SCANport Feedback Output there are 16 additional 16 bit words
which can be exchanged between an Allen-Bradley PLC and the drive.
Data Word
Data Link
Identifier
8720MC
Parameter
Assignment
Default Link
8720MC Data Description
Data Type
(16 bit word)
Input Word 0
Logic Command
717
717
SCANport Logic Command Word
Bit Pattern
Input Word 1
Command Reference 713
713
SCANport velocity/torque Input
Reference Value
Signed Integer
Input Word 2
Data In A1
725
36
SCANport Velocity Reference Value
Signed Integer
Input Word 3
Data In A2
726
258
Target Position
±32,768 resolution units
Signed Integer
Input Word 4
Data In B1
727
153
Orient Angle
Signed Integer
Input Word 5
Data In B2
728
259
Positioning Velocity
Signed Integer
Input Word 6
Data In C1
729
260
Positioning Acceleration
Signed Integer
Input Word 7
Data IN C2
730
222
Orient Speed
Signed Integer
Input Word 8
Data IN D1
731
154
Orient Options
Signed Integer
Input Word 9
Data In D2
732
Reserved
Signed Integer
Output Word 0
Logic Status
718
718
SCANport Logic Status Word
Bit Pattern
Output Word 1
Velocity Feedback
715
40
SCANport Velocity Feedback
Signed Integer
Output Word 2
Data Out A1
733
11
Shut Down Errors
Bit Pattern
Output Word 3
Data Out A2
734
129
8720MC Drive Errors
Bit Pattern
Output Word 4
Data Out B1
735
13
Drive Status
Bit Pattern
Output Word 5
Data Out B2
736
386
Motor Shaft power
Integer
Output Word 6
Data Out C1
737
254
Actual parameter set
Binary 0 -7
Output Word 7
Data Out C2
738
Reserved
Signed Integer
Output Word 8
Data Out D1
739
347
Velocity Error
Signed Integer
Output Word 9
Data Out D2
740
84
Torque Feedback
Signed Integer
