Publication 8720MC-IN002A-EN-P — December 2002
Programming Parameters C-31
Name: Mtr_Torq_Overld Data Display: Signed Decimal R/W
Parameter No.
114
File:
Linear List
Group:
Linear List Description: When the load limit is exceeded for a period of time, the overload shut-down bit 0 of C1D (parameter
11) is set.
Default:
100.0 Length
2 bytes SCANport Min/Max
Min. > 0
Max.
≤ 1,000
SCANport Scaling Resolution
1 = 0.1% Units
%
Default:
100.0 Length
2 bytes SERCOS/DPI Min/Max
Min.
≥ -2 15
Max.
≤ +2 15
- 1
SERCOS/DPI Scaling Resolution
Scaling type: parameter 86
Scaling factor: parameter 93
Scaling exponent: parameter 94 Units
Parameter
86
Name: Motor_Fdbk_Resol Data Type: Integer R/W
Parameter No.
116
File:
Motor/Drive/
Fdbk
Group:
Motor Feedback Description: For rotary feedback the resolution parameter of feedback 1 (motor feedback) defines the number of
cycles per revolution of the motor. For a sinusoidal device this represents the number of periods per revolution.
For a TTL devices this represents the number of lines per motor revolution. For a linear feedback the grid constant
is entered. For the standard Stegmann motor feedback devices this will be self identified at 1024 counts.
Default:
From motor
encoder Length
2 bytes SCANport Min/Max
Min. > 0
Max.
≤ 32,000
SCANport Scaling Resolution
1 = 1 cycle/motor revolution Units
fdbk cycles
Default:
From motor
encoder Length
4 bytes SERCOS/DPI Min/Max
Min. > 0
Max. ≤ 2 32
- 1
SERCOS/DPI Scaling Resolution
1 [cycles/motor revolution] Units
fdbk cycles
Name: Gear_In_Revs_0 Data Display: Integer R/W
Parameter No.
121
File:
Servo Loop
Group:
Group 0 Description: Input revolutions of load gear set as viewed from the motor. Input revolutions must be entered as an
integer value. This parameter applies to the SERCOS interface only.
Analog Default:
1 Length
2 bytes SCANport Min/Max
Min.
≥ 0
Max.
≤ +65535
SCANport Scaling Resolution
1 revolution of the input shaft Units
revs
Default:
1 Length
4 bytes SERCOS/DPI Min/Max
Min.
≥ 0
Max.
≤ +2 32
- 1
SERCOS/DPI Scaling Resolution
1 [input revolution] Units
revs
