Publication 8720MC-IN001D-EN-P — December 2002
8720SM Motor Specifications and Performance Curves D-5
8720MC Drive Amplifier Specifications
8720MC Line Reactor Specifications
8720MC Drive Amplifier Specifications for 750V dc Input 8720MC-RPS Regenerative Power Supply and 8720SM AC Motor
Drive Amp. Specifications Units Drive Amplifier Data for Each Power Rating
Motor catalog number 8720SM- 005S1BA 007S1CA 011S1DA 015S2EA 018S2FA 022S2GA 030S4JA 037S4KA
Rated continuous motor
current at base speed Amps
(RMS cont.)
13.5 20.3 26.8 33.4 41.4 48 63.1 76.1
Drive amplifier catalog no. 8720MC- B014 B021 B027 B034 B042 B048 D065 D078
DC input current @750V dc Amps 8.9 12.1 16.9 23.3 28.4 33.4 44.1 53.8
Max cont. output power kW (hp) 5.5 (7.5) 7.5 (10) 11 (15) 15 (20) 18.5 (25) 22 (30) 30 (40) 37 (50)
Max cont. output current Amps (RMS) 14 21 27 34 42 48 65 78
Drive amplifier frame B B B B B B C C
DC Bus Capacitance µF 1350 1350 2150 2150 4300 4300 6450 6450
Rated operating temp. (open) deg C 0 to 50 0 to 50 0 to 50 0 to 50 0 to 50 0 to 50 0 to 50 0 to 50
Weight kg (lbs) 22.7 (50) 22.7 (50) 22.7 (50) 22.7 (50) 22.7 (50) 22.7 (50) 38.6 (85) 38.6 (85)
8720MC Line Reactor Specifications for 750V dc Input Drives with 8720MC-RPS Regenerative Power Supply and 8720SM AC Motor
Line Reactor
Specifications
Units Line Reactor Data for Each Power Rating
Motor catalog number 8720SM- 005S1BA 007S1CA 011S1DA 015S2EA 018S2FA 022S2GA 030S4JA 037S4KA
Req. RPS continuous Input
current
Amps (RMS) 9 12 18 25 31 36 50 61
Drive amplifier catalog no. 8720MC- B014 B021 B027 B034 B042 B048 D065 D078
Line Reactor catalog no. 8720MC- LR03-032B LR03-032B LR03-032B LR03-032B LR05-048B LR05-048B LR10-062B LR10-062B
Max cont. current Amps (RMS) 32 32 32 32 48 48 62 62
Inductance uH 850 850 850 850 800 800 1100 1100
Weight kg (lbs) 17 (37.4) 17 (37.4) 17 (37.4) 17 (37.4) 21 (46.2) 21 (46.2) 27 (59.4) 27 (59.4)
